Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Work surface thickness | 25 mm | |
| Edge trim thickness | 1 mm | |
| Left support panel width | 600 mm | |
| Knee clearance width | 700 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance depth | 450 mm | |
| Right pedestal width | 400 mm | |
| Top drawer internal dimensions | 350 x 500 x 100 mm | |
| Lower cabinet internal height | 500 mm | |
| Open under-pedestal shelf height | 200 mm | |
| Leveling foot adjustment height | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Leveling foot load rating per foot | 40 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight and equipment | 136 kg | |
| Product net weight | 45 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 18mm MDF core with dark wood grain thermal-fused laminate | |
|---|---|---|
| Edge trim | 0.8mm light gold polished metal trim bonded to desk edges | |
| Vertical support panels | 16mm particle board with matching dark wood grain laminate | |
| Knee well interior | 15mm black matte melamine panel | |
| Drawer glides | Cold-rolled steel full-extension Euro-style slides | |
| Leveling feet | Black injection-molded PP with threaded steel insert |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Drawer locking function | Keyed cam lock secures top drawer for private item storage | |
|---|---|---|
| Floor leveling | Threaded adjustable feet compensate for 10mm floor height variation | |
| Seated work access | Central knee recess accommodates standard office chairs for upright work | |
| Storage organization | Combination of shallow drawer, enclosed cabinet and open shelf for supplies |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Shipping carton dimensions | 1260 x 660 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Suitable for compact home workspaces with laptop and document storage | |
|---|---|---|
| Small business individual workstation | Cost-effective single-user desk for startup and small office layouts |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for performanceAcceptance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for pedestal storage | |
| EN 13722:2004 | Furniture strength and durability assessment for office work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static and cyclic load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for pedestal drawer and shelf loads |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural safety | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for indoor wooden furniture, required for indoor use | |
| GB/T 4897.3-2003 | Particle board for furniture use, applicable for structural panel substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural safety; 2. GB 18584-2001: Limit of formaldehyde emission for indoor wooden furniture, required for indoor use; 3. GB/T 4897.3-2003: Particle board for furniture use, applicable for structural panel substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
