Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1200 x 610 x 750 mm | |
|---|---|---|
| Desktop work surface thickness | 18 mm | |
| PVC edge banding thickness | 3 mm | |
| Under-desk seated knee clearance height | 718 mm | |
| Under-desk knee clearance width | 660 mm | |
| Under-desk knee clearance depth | 450 mm | |
| Upper storage drawer internal dimensions | 390 x 500 x 120 mm | |
| Lower cabinet compartment internal height | 430 mm | |
| Cable grommet inner diameter | 60 mm | |
| Desk base leveling foot height adjustment | 25 mm | |
| Left panel leg cross-section | 610 x 750 mm | |
| Pedestal base foot height | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 68 kg | |
|---|---|---|
| Desk net weight | 43 kg | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Finish scratch resistance rating | 2000 abrasion cycles | |
| Recommended maximum user weight load | 110 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and panel substrate | 18mm E1-grade particle board | |
|---|---|---|
| Surface finish | Melamine laminate with light oak woodgrain and matte white finish | |
| Edge treatment | 3mm PVC edge banding on all exposed panel edges | |
| Drawer slides | Cold-rolled steel roller slides | |
| CPU compartment panel | Ventilated melamine panel with slotted and circular vents | |
| Leveling feet | Injection-molded polypropylene adjustable feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Two 60mm cable grommets at left and right desktop sections | |
|---|---|---|
| CPU storage | Vented lower cabinet compartment with dedicated airflow openings | |
| Drawer storage | Single lockable upper drawer for small office supplies | |
| Leveling adjustment | Four adjustable polypropylene feet at the desk base |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small home office workspaces | Compact 1200mm width fits tight residential work areas with storage | |
|---|---|---|
| Open-plan staff workstations | Standard 750mm work height supports standard office chairs for daily administrative tasks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applies to structural load testing | |
|---|---|---|
| EN 14372:2004 | Office furniture hardware performance, applies to drawer slide durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applies to static load and stability validation | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applies to drawer and cabinet performance checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, sets E1 ≤0.124mg/m³ limit | |
| GB/T 4897-2015 | Particle board quality standard, applies to structural substrate performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, sets E1 ≤0.124mg/m³ limit; 3. GB/T 4897-2015: Particle board quality standard, applies to structural substrate performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
