Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| desktop thickness | 28 mm | |
| desktop edge band thickness | 3 mm | |
| left storage pedestal width | 450 mm | |
| central knee clearance width | 850 mm | |
| knee clearance height | 620 mm | |
| knee clearance depth | 500 mm | |
| cable grommet diameter | 60 mm | |
| modesty panel height | 400 mm | |
| adjustable glide height adjustment range | 25 mm | |
| upper pedestal drawer internal height | 120 mm | |
| lower file drawer internal height | 280 mm | |
| right end support panel thickness | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static load capacity | 136 kg | |
|---|---|---|
| drawer slide cycle durability | 50000 cycles | |
| surface scratch resistance rating | 2 N | |
| product net weight | 81 kg | |
| adjustable glide static load per foot | 68 kg | |
| recommended maximum user weight for seated use | 150 kg | |
| cable grommet cable capacity | 8 standard power/data cables | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop core | 45 lb density industrial grade particleboard | |
|---|---|---|
| desktop surface | Thermal-fused dark wood grain melamine laminate | |
| edge banding | 3 mm thick dark grey PVC T-mold edge | |
| support panels and pedestal | Laminated engineered wood panels | |
| modesty panel | Dark grey matte laminated fiberboard | |
| hardware components | Steel ball-bearing drawer slides, plastic cable grommets, nylon glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| cable management | Two recessed desktop grommets route power and data cables from surface to floor | |
|---|---|---|
| pedestal storage | Two-lockable drawer configuration with upper supply drawer and lower hanging file drawer | |
| floor leveling | Four adjustable nylon glides compensate for uneven floor surfaces for stable desktop alignment | |
| privacy screening | Fixed full-width modesty panel blocks view of under-desk area from seated front position |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| private office workstations | Suitable for individual staff use with integrated storage and cable management for laptop/desktop setups | |
|---|---|---|
| open plan office clusters | Modest footprint fits standard office grid layouts without extended returns or oversize space requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to desk height and clearance requirements | |
|---|---|---|
| EN 527-2:2002 | Office work tables - Part 2: Mechanical safety requirements, applicable to load and stability testing | |
| EN 14073-2:2004 | Office furniture - Storage furniture - Part 2: Safety requirements, applicable to pedestal drawer performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for performance, durability and structural stability for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Performance and durability requirements for pedestal drawer units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural performance and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to desktop core material performance specifications | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural performance and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to desktop core material performance specifications; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
