Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Desktop thickness | 18 mm | |
| Central knee clearance width | 600 mm | |
| Under-desk knee clearance height | 600 mm | |
| Keyboard tray usable dimensions | 650 x 300 x 50 mm | |
| Left pedestal dimensions | 400 x 500 x 680 mm | |
| Single drawer internal dimensions | 350 x 450 x 150 mm | |
| Right CPU cabinet internal dimensions | 250 x 480 x 500 mm | |
| Cable grommet diameter | 60 mm | |
| Leveling foot height adjustment | 10 mm | |
| Desktop overhang front/back | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 130 kg | |
|---|---|---|
| Product net weight | 45 kg | |
| Recommended user weight capacity | 136 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and drawer/door fronts | 18mm engineered particleboard with light oak wood-effect melamine laminate | |
|---|---|---|
| Pedestal side panels and back panels | 15mm engineered MDF with matte white melamine finish | |
| Edge banding | 1mm PVC edge banding matching finish on all exposed panel edges | |
| Drawer and door hardware | Brushed silver-finish zinc alloy pulls with steel roller drawer glides | |
| Lock mechanism | Keyed cam lock securing top left drawer, keyed alike per unit | |
| Leveling feet | 10mm height-adjustable polypropylene feet with non-slip rubber base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Keyboard tray operation | Smooth under-desk pull-out tray with positive stop in extended position | |
|---|---|---|
| Cable management | Two 60mm desktop grommets routed to under-desk and CPU compartment pass-throughs | |
| CPU compartment ventilation | Vertical louvered vent panel on inner cabinet face for passive PC cooling | |
| Drawer security | Keyed lock on left top drawer secures valuables, lower drawers operate freely |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workspace | Suitable for individual remote work or study with integrated storage for PC and supplies | |
|---|---|---|
| Small business staff workstation | Designed for general administrative staff in open plan or private office settings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for non-height-adjustable desks | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture, safety and strength requirements for pedestals and cabinets | |
| EN 13722:2004 | Office furniture, test methods for strength and durability of storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard for performance of attached drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel furniture structural integrity | |
|---|---|---|
| GB/T 17657-2013 | Test methods for evaluating surface physical and chemical properties of wood-based panels | |
| GB 18584-2001 | Limit of formaldehyde emission for interior decoration wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel furniture structural integrity; 2. GB/T 17657-2013: Test methods for evaluating surface physical and chemical properties of wood-based panels; 3. GB 18584-2001: Limit of formaldehyde emission for interior decoration wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
