Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 700 x 760 mm | |
|---|---|---|
| Desktop thickness | 29 mm | |
| ABS edge band thickness | 2 mm | |
| Knee clearance width | 720 mm | |
| Knee clearance height under modesty panel | 620 mm | |
| Knee clearance depth under work surface | 450 mm | |
| Right pedestal dimensions | 500 x 600 x 690 mm | |
| Upper drawer internal dimensions | 430 x 520 x 120 mm | |
| Lower cabinet internal dimensions | 430 x 520 x 500 mm | |
| Cable grommet diameter | 60 mm | |
| Black modesty panel dimensions | 700 x 450 mm | |
| Left support panel thickness | 25 mm | |
| Leveling foot height adjustment | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Evenly distributed desktop static load | 136 kg | |
|---|---|---|
| Upper drawer maximum static load | 20 kg | |
| Lower cabinet shelf maximum static load | 30 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and wood-grain panels | E0-grade MFC board with thermally fused light oak laminate | |
|---|---|---|
| Modesty panel and pedestal accent panels | Matte black melamine-faced particle board | |
| Edge banding | 2 mm thick ABS edging with matching light oak/black finish | |
| Drawer slides | 3-section full-extension silent ball-bearing steel slides | |
| Cabinet hinges | Soft-close steel concealed hinges | |
| Pedestal lock | Mechanical combination lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed desktop grommet routes power/data cables to under-desk space | |
|---|---|---|
| Storage access | Upper lockable drawer plus lower cabinet door provides secured office storage | |
| Stability adjustment | Four leveling feet adjust to compensate for uneven floor surfaces | |
| Computer storage | Dedicated lower cabinet bay accommodates full-size vertical desktop tower |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private manager office | Suitable for individual executive work with secured storage for documents | |
|---|---|---|
| Open office workstation | Functions as a dedicated individual desk for administrative or professional staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable to safety and dimensional requirements for office work desks | |
|---|---|---|
| EN 527-2:2016 | Applicable to mechanical safety and stability requirements for office desks | |
| EN 13722:2004 | Applicable to storage furniture performance for office pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable to desk products safety and performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable to storage pedestals and office cabinet performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to general technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Applicable to particleboard used for furniture structural components | |
| GB 18580-2017 | Applicable to formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to general technical requirements for wooden office furniture; 2. GB/T 4897.3-2003: Applicable to particleboard used for furniture structural components; 3. GB 18580-2017: Applicable to formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
