Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Work surface thickness | 25 mm | |
| Work surface height from floor | 750 mm | |
| Seated knee clearance width | 650 mm | |
| Seated knee clearance height under desktop | 600 mm | |
| Storage pedestal dimensions | 550 x 500 x 700 mm | |
| Upper drawer internal dimensions | 400 x 430 x 120 mm | |
| Lower cabinet internal dimensions | 400 x 480 x 520 mm | |
| Raised secondary shelf dimensions | 550 x 300 x 80 mm | |
| Cable grommet diameter | 60 mm | |
| Left solid panel leg thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Leveling foot height adjustment | 15 mm | |
| Pedestal side vent grille dimensions | 250 x 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static load capacity of work surface | 60 kg | |
|---|---|---|
| Cable grommet cable routing capacity | 6 cables | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Surface finish abrasion resistance | 300 revolutions | |
| Net product weight | 35 kg | |
| Recommended maximum user weight for desktop use | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1 grade particleboard with light oak melamine finish | |
|---|---|---|
| Left leg panel and pedestal drawer/cabinet fronts | 18mm E1 grade particleboard with matching light oak melamine | |
| Pedestal inner side and modesty panel | 18mm E1 grade particleboard with matte white melamine finish | |
| Edge banding | 2mm thick PVC edge banding on all exposed edges | |
| Drawer slides and hardware | Cold-rolled steel full-extension ball-bearing slides | |
| Leveling feet | Polypropylene base with steel threaded stud |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Left-top 60mm grommet routes desktop cables to under-desk area | |
|---|---|---|
| Storage configuration | 1 upper shallow drawer plus 1 lower vented cabinet door | |
| CPU compartment ventilation | Side vent grille with horizontal slats promotes passive airflow | |
| Floor leveling | Four adjustable polymer feet compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstations | Compact footprint fits small spaces, integrated storage reduces need for separate cabinets | |
|---|---|---|
| Small commercial office spaces | Standard working height and clearance meets daily seated office tasks |
EU Market Access Requirements* EN Standards
| EN 527-2:2016 | Safety and strength requirements for office work tables, applies to commercial-grade use |
|---|
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products test standard for structural durability and load performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to structural safety and finish | |
|---|---|---|
| GB/T 3327-2018 | Performance test methods for desks and tables, applies to static load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applies to E1 grade panel requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to structural safety and finish; 2. GB/T 3327-2018: Performance test methods for desks and tables, applies to static load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applies to E1 grade panel requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
