Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 580 x 670 x 1010 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat width | 550 mm | |
| Seat depth | 460 mm | |
| Backrest height | 550 mm | |
| Armrest height above seat | 220 mm | |
| Leg footprint width | 530 mm | |
| Leg footprint depth | 620 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest channel padding thickness | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 31 kg | |
|---|---|---|
| Recommended static user load | 150 kg | |
| Seat foam density | 50 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Structural warranty | 5 years | |
| Standard color option count | 1 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary frame | Kiln-dried solid bentwood with 5-coat water-based reddish-brown lacquer finish | |
|---|---|---|
| Seat/back support panels | 15 mm thick multi-layer bent plywood | |
| Seat upholstery | 1.3 mm thick black PU leather, breathable, fade-resistant | |
| Back upholstery | 1.3 mm thick black PU leather with horizontal segmented channel stitching | |
| Seat padding | High-resilience cold-cured polyurethane foam | |
| Back padding | High-resilience molded polyurethane foam with lumbar support contour | |
| Hardware fasteners | Zinc-plated steel screws and dowel connectors | |
| Leg floor glides | Non-marking polyethylene protective foot pads | |
| Stretcher supports | Solid wood horizontal cross braces between legs for structural rigidity | |
| Seam construction | Double-stitched seams with 8 mm stitch pitch for seam durability | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | No height adjustment, fixed seated position optimized for conference table use | |
|---|---|---|
| Swivel function | No swivel rotation, fixed static seating position | |
| Tilt/recline function | No tilt or recline mechanism, fixed upright posture for formal meetings | |
| Armrest support | Integrated curved bentwood armrests connecting front legs to back frame for continuous upper body support | |
| Lumbar support | 5 horizontal segmented padded back channels provide targeted mid-back lumbar support | |
| Mobility | Stationary, no casters, designed for fixed placement in conference and meeting spaces | |
| Stacking capability | Non-stacking, solid frame construction for heavy-duty commercial use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate conference rooms | Formal upright posture suits extended meetings with standard 750mm conference tables | |
|---|---|---|
| Executive reception areas | Classic red-brown wood and black leather aesthetic creates a professional visitor impression | |
| Training room seating | Fixed stable structure provides durable seating for regular training sessions | |
| Government meeting halls | Conservative formal design matches official government and institution meeting spaces | |
| Office visitor seating | Sturdy construction provides reliable seating for office guests and interview candidates | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applicable standard for office furniture office chair dimensional stability requirements | |
|---|---|---|
| EN 1335-2:2018 | Applicable standard for office chair safety strength and durability requirements | |
| EN 1022:2018 | Applicable standard for furniture seating stability test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable standard for general purpose office chair safety and performance requirements |
|---|
Standards applicable to China-market projects
| GB 18584-2001 | Applicable standard for formaldehyde emission limits for wooden furniture indoor use | |
|---|---|---|
| GB/T 16799-2008 | Applicable standard for polyurethane leather used for furniture upholstery |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable standard for formaldehyde emission limits for wooden furniture indoor use; 2. GB/T 16799-2008: Applicable standard for polyurethane leather used for furniture upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
