| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 580 x 670 x 1010 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat surface size | 500 x 500 mm | |
| Backrest height | 630 mm | |
| Armrest height above floor | 650 mm | |
| Armrest clearance above seat | 200 mm | |
| Leg footprint width | 530 mm | |
| Leg footprint depth | 620 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 24 kg | |
|---|---|---|
| Recommended static user load | 150 kg | |
| Seat foam density | 50 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Seam stitch pitch | 8 mm | |
| Limited commercial warranty | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Support frame | Solid bent hardwood with polished red-brown lacquer finish | |
|---|---|---|
| Seat/back inner panel | 12 mm thick high-density plywood | |
| Seat upholstery | 1.2 mm thick black bonded leather with stitched segmented panels | |
| Backrest upholstery | Black bonded leather matching seat, with vertical and horizontal stitch lines | |
| Armrests | Integrated solid bentwood matching frame, lacquered to match leg finish | |
| Leg pads | Non-marking hard plastic floor glides at each leg base | |
| Frame fasteners | Zinc-plated steel bracket connecting armrest to back frame | |
| Padding core | High-resilience polyurethane foam under all upholstered surfaces | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating support | Fixed non-swivel, non-height-adjustable four-leg base for stable boardroom use | |
|---|---|---|
| Back support | Contoured segmented high back with integrated lumbar support zone | |
| Arm support | Fixed integrated wooden armrests positioned for neutral seated elbow rest | |
| Floor protection | Hard plastic glides prevent hard floor scratching without rolling movement | |
| Upholstery durability | Abrasion resistance rated for 50000 double rubs | |
| Frame stability | Four-point floor contact eliminates wobble on level commercial flooring | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Boardroom meeting spaces | Formal high-back styling matches executive conference table aesthetics | |
|---|---|---|
| Executive private offices | Polished wood frame complements traditional office furniture suites | |
| Government and institutional meeting rooms | Conservative black/wood finish aligns with formal institutional decor | |
| Training and reception areas | Fixed stable base provides secure seating for multi-purpose visitor use | |
| Hotel business centers | Durable commercial construction supports high-traffic guest and event use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office furniture seating safety standard | EN 1335:2020 | |
|---|---|---|
| Upholstered furniture durability standard | EN 16139:2013 |
US and Canada office-furniture standards
| Lounge and conference seating standard | ANSI/BIFMA X2020 |
|---|
Standards applicable to China-market projects
| Office chair dimensional standard | GB/T 3326 | |
|---|---|---|
| Furniture mechanical performance standard | GB/T 10357.3 | |
| Upholstered furniture material standard | GB/T 16799 |
This product must meet the following technical requirements: 1. Office chair dimensional standard: GB/T 3326; 2. Furniture mechanical performance standard: GB/T 10357.3; 3. Upholstered furniture material standard: GB/T 16799; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
