Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 700 × 670 × 1100 mm | |
|---|---|---|
| Seat height | 480 mm | |
| Seat width | 520 mm | |
| Seat depth | 510 mm | |
| Backrest height | 680 mm | |
| Armrest height from floor | 650 mm | |
| Armrest width | 80 mm | |
| Leg spread width (front) | 620 mm | |
| Seat cushion thickness | 100 mm | |
| Backrest cushion thickness | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 26 kg | |
|---|---|---|
| Recommended static load capacity | 150 kg | |
| Recommended daily use duration | 6 hours | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Overall frame warranty | 5 years | |
| Available color options | 2 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame and legs | Solid rubberwood with walnut glossy lacquer finish | |
|---|---|---|
| Upholstery | 1.2mm thick black PU faux leather | |
| Seat padding | High-density polyurethane foam | |
| Backrest padding | Contoured high-resilience foam | |
| Headrest padding | Integrated molded foam cushion | |
| Armrest pads | PU faux leather over foam padding | |
| Wood frame finish | Multi-layer scratch-resistant polyurethane lacquer | |
| Frame treatment | Damp-proof and insect-proof preserved wood | |
| Seam stitching | High-tensile polyester thread, 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Stationary fixed-position seating for reception/conference use | |
|---|---|---|
| Back support | Contoured ergonomic back with integrated headrest | |
| Arm support | Fixed curved wood armrests with padded tops | |
| Adjustability | No height, tilt, swivel or recline adjustment | |
| Surface maintenance | Stain-resistant wipe-clean upholstery | |
| Structural stability | Four-point fixed leg support with anti-slip floor pads | |
| Edge protection | Piped stitched edges on seat and back panels | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Carton dimensions | 750 x 700 x 1300 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive reception areas | Formal styling for guest seating outside executive offices | |
|---|---|---|
| Conference/meeting rooms | Fixed comfortable seating around conference tables for meetings | |
| Boardroom settings | High-back executive design for formal boardroom attendee seating | |
| Government/institutional offices | Durable solid wood construction meets public sector procurement standards | |
| VIP waiting areas | Padded high-back support for extended visitor waiting comfort | |
| Manager office guest seating | Matches traditional executive desk suites for in-office visitor chairs | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Applicable safety requirements for office seating | |
|---|---|---|
| EN 1021-1:2014 | Applicable upholstered furniture ignition resistance (cigarette test) |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable general purpose office chairs strength/durability |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture | |
|---|---|---|
| GB/T 16799-2008 | Applicable for PU artificial leather upholstery material | |
| GB 18584-2001 | Applicable for formaldehyde emission limits for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture; 2. GB/T 16799-2008: Applicable for PU artificial leather upholstery material; 3. GB 18584-2001: Applicable for formaldehyde emission limits for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
