Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 660 x 686 x 924 mm | |
|---|---|---|
| Seat width | 584 mm | |
| Seat depth | 533 mm | |
| Seat height (to floor) | 460 mm | |
| Backrest width | 540 mm | |
| Backrest height (from seat) | 420 mm | |
| Seat cushion thickness | 100 mm | |
| Backrest cushion thickness | 90 mm | |
| Armrest height (from floor) | 660 mm | |
| Internal arm-to-arm width | 483 mm | |
| Leg cross-section | 45 x 45 mm | |
| Under-seat knee clearance height | 260 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 21.8 kg | |
|---|---|---|
| Recommended static load capacity | 125 kg | |
| Seat foam density | 60 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Wood frame static load rating | 300 kg | |
| Available finish options | 2 | |
| Warranty period | 6 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame, arms and legs | Solid hardwood with reddish cherry multi-coat baked lacquer finish | |
|---|---|---|
| Seat upholstery | 1.2 mm thick black commercial-grade PU leather | |
| Backrest upholstery | 1.2 mm thick black commercial-grade PU leather | |
| Seat padding | Cold-molded high-resilience polyurethane foam | |
| Backrest padding | Cold-molded high-resilience polyurethane foam | |
| Internal seat support | 12 mm thick plywood panel with no-sag spring support | |
| Frame joinery | Mortise-and-tenon joints reinforced with steel wood screws | |
| Leg floor glides | Non-marking polyethylene glides affixed to leg bottoms | |
| Wood surface treatment | Multi-layer UV-cured lacquer with satin sheen | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Adjustment functionality | No swivel, tilt, height adjustment or recline mechanisms | |
|---|---|---|
| Mobility | Stationary seating, no casters, rests on fixed legs with protective glides | |
| Armrest support | Integrated curved solid wood armrests connecting front legs to back frame | |
| Seat ergonomics | Contoured padded seat with waterfall front edge to reduce leg pressure | |
| Back support | Upright mid-back padded panel providing lumbar support for meeting use | |
| Cleaning compatibility | Non-porous upholstery surface allows wipe-down cleaning with standard disinfectants | |
| Stacking capability | Non-stackable fixed-frame construction | |
| Assembly design | Knock-down construction with bolted leg-to-frame connections for easy shipping | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Conference room seating | Suitable for formal meeting rooms, matching traditional executive wood office furniture | |
|---|---|---|
| Reception/waiting areas | Appropriate for office lobbies and guest waiting zones with durable easy-clean upholstery | |
| Executive office visitor seating | Designed for placement in front of executive desks for guest use | |
| Training room seating | Suitable for long-duration seated use in corporate training and boardroom spaces | |
| Government/institution seating | Matches formal aesthetic requirements for government and institutional meeting spaces | |
| Recommended configuration | Deploy in sets of 8around standard conference tables for unified formal styling | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Applies to safety requirements for non-adjustable office visitor seating | |
|---|---|---|
| EN 1022:2018 | Applies to stability testing for domestic and contract seating | |
| EN 12520:2015 | Applies to strength, durability and safety requirements for contract seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair safety and performance criteria for visitor chairs |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to dimensional tolerance and stability requirements for wooden office seating | |
|---|---|---|
| GB/T 16799-2008 | Applies to performance requirements for PU leather upholstery materials | |
| GB 18584-2001 | Applies to limit of harmful formaldehyde emissions for wooden furniture | |
| GB/T 10357.3-2013 | Applies to strength and durability test methods for chair seating |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to dimensional tolerance and stability requirements for wooden office seating; 2. GB/T 16799-2008: Applies to performance requirements for PU leather upholstery materials; 3. GB 18584-2001: Applies to limit of harmful formaldehyde emissions for wooden furniture; 4. GB/T 10357.3-2013: Applies to strength and durability test methods for chair seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
