Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 630 × 670 × 1080 mm | |
|---|---|---|
| Armrest width | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static user weight capacity | 160 kg | |
|---|---|---|
| Net product weight | 15 kg | |
| Seat foam density | 50D | |
| Backrest foam density | 40D | |
| Foam rebound rate | 60% | |
| Foam compression durability cycles | 300000 | |
| Seat base plywood thickness | 18 mm | |
| Structure warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Support frame and legs | Solid red-brown hardwood with polished varnish finish | |
|---|---|---|
| Seat and backrest upholstery | 1.2mm thick black wear-resistant PU leather | |
| Seat padding core | 50D high-resilience molded polyurethane foam | |
| Backrest padding core | 40D contoured high-resilience polyurethane foam | |
| Seat support board | 18mm thick multi-layer plywood under seat cushion | |
| Frame-to-upholstery fasteners | Zinc-plated steel screws and brackets | |
| Frame surface finish | Clear UV-cured varnish with wear-resistant topcoat | |
| Stitching seam pitch | 3 stitches per 10mm | |
| Armrest construction | Integrated curved solid wood connected to front legs and back frame | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Frame adjustment capability | Fixed non-swivel, non-tilting, non-height-adjustable rigid structure | |
|---|---|---|
| Back support design | Segmented ergonomic high back with built-in lumbar contour | |
| Armrest functionality | Fixed rigid wood armrests providing stable upper extremity support | |
| Seat comfort design | Rounded front seat edge to reduce lower leg pressure | |
| Stability design | Four outwards-angled solid wood legs for anti-tip static stability | |
| Surface maintenance | Stain-resistant smooth leather surface for wet wiping and cleaning | |
| Assembly requirement | Fully assembled delivery for direct placement without on-site build | |
| Floor protection | Hidden felt pads at leg bottoms to prevent hard floor scratching | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate conference rooms | Formal fixed seating for long meetings, upright posture support | |
|---|---|---|
| Executive office guest areas | Formal visitor seating matching traditional executive office decor | |
| Government and institutional meeting spaces | Durable formal seating compliant with public furniture procurement requirements | |
| Traditional style private studies | Home office seating matching classic solid wood study furniture sets | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applicable European standard for office chair dimensional stability requirements | |
|---|---|---|
| EN 1335-2:2018 | Applicable European standard for office chair strength and durability testing | |
| EN 1022:2018 | Applicable European standard for domestic and contract seating stability testing |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable American standard for general purpose office chair performance requirements |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for wooden furniture, defining material and finish requirements | |
|---|---|---|
| GB 18584-2001 | Applicable standard for formaldehyde emission limits in wood furniture | |
| GB/T 19001-2016 | Applicable quality management system reference for production quality control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for wooden furniture, defining material and finish requirements; 2. GB 18584-2001: Applicable standard for formaldehyde emission limits in wood furniture; 3. GB/T 19001-2016: Applicable quality management system reference for production quality control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
