Freestanding Double-Rail Garment Rack with Hook Bar and Slatted Shoe Shelf (model CGR-2RAIL-8HOOK-SHELF) is listed under coat rack. Dimensions: 700 x 300 x 1800 mm. Materials: 30 x 30 mm square steel tubes with 1.0 mm wall, welded side frames and dark powder coating. Load capacity: 30 kg. Product Features: freestanding,structure,double-rail,design,open,slatted,shelf,dark,metal,finish. This page consolidates 6 groups of specifications and GB standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | 0777 | Model | CGR-2RAIL-8HOOK-SHELF |
| Overall dimensions | 700 x 300 x 1800 mm | Carcass Panel Thickness | 25 mm |
| Back Panel Thickness | 9 mm | Door / Drawer Front Thickness | 22 mm |
| Shelf Thickness | 25 mm | Upper hanging-rail static load | 30 kg |
| Lower hanging-rail static load | 25 kg | Hook-bar total static load | 20 kg |
| Single-hook static load | 3 kg | Lower shelf uniformly distributed load | 20 kg |
| Overall rack static load | 60 kg | Stability overturning limit | 15 kg off-center load at 1500 mm |
| Foot contact floor load | 40 kg per foot point | Durability cycles | 10,000 hanger sliding cycles |
| Assembly fastener torque retention | 24 h under loaded rack condition | Side uprights | 30 x 30 mm square steel tubes with 1.0 mm wall, welded side frames and dark powder coating |
| Garment rails | 28 mm diameter round steel tubes with 1.0 mm wall, horizontally bolted between uprights | Hook bar | 25 mm diameter steel tube with six integrated double-prong hook saddles and rounded end stops |
| Lower shelf slats | 16 x 16 mm square steel bars spaced in four open rows and welded to perimeter frame | Base perimeter frame | 25 x 25 mm steel rectangle connecting the four feet and supporting the shelf |
| Frame finish | Dark bronze polyester powder coating over phosphate-treated steel, 0.06 mm cured film | Cable / Vent Opening Reference | If fitted, 80 mm diameter |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | Reference Packaged Gross Weight | 100 kg/set in 3 cartons |
| Reference Packaging Volume | 0.65 m³/set | Home entryway for two to four users | the 700 mm footprint fits beside a doorway while the 1680 mm hook bar separates bags from hanging coats. |
| Bedroom or rental apartment dressing area | double rails at 1530 mm and 1440 mm support everyday outfits and shorter garments without occupying closet depth. | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 700 x 300 x 1800 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Upper hanging-rail static load | 30 kg | |
|---|---|---|
| Lower hanging-rail static load | 25 kg | |
| Hook-bar total static load | 20 kg | |
| Single-hook static load | 3 kg | |
| Lower shelf uniformly distributed load | 20 kg | |
| Overall rack static load | 60 kg | |
| Stability overturning limit | 15 kg off-center load at 1500 mm | |
| Foot contact floor load | 40 kg per foot point | |
| Durability cycles | 10,000 hanger sliding cycles | |
| Assembly fastener torque retention | 24 h under loaded rack condition |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Side uprights | 30 x 30 mm square steel tubes with 1.0 mm wall, welded side frames and dark powder coating | |
|---|---|---|
| Garment rails | 28 mm diameter round steel tubes with 1.0 mm wall, horizontally bolted between uprights | |
| Hook bar | 25 mm diameter steel tube with six integrated double-prong hook saddles and rounded end stops | |
| Lower shelf slats | 16 x 16 mm square steel bars spaced in four open rows and welded to perimeter frame | |
| Base perimeter frame | 25 x 25 mm steel rectangle connecting the four feet and supporting the shelf | |
| Frame finish | Dark bronze polyester powder coating over phosphate-treated steel, 0.06 mm cured film |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
|---|
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home entryway for two to four users | the 700 mm footprint fits beside a doorway while the 1680 mm hook bar separates bags from hanging coats. | |
|---|---|---|
| Bedroom or rental apartment dressing area | double rails at 1530 mm and 1440 mm support everyday outfits and shorter garments without occupying closet depth. |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| GB/T 3324-2024 General Technical Requirements for Wooden Furniture | use only as an acceptance reference for dimensional tolerances if wood components are later substituted; current visible product is metal. | |
|---|---|---|
| GB/T 3325-2017 General Technical Requirements for Metal Furniture | recommended reference for metal-furniture workmanship, coating appearance, and structural acceptance. | |
| GB/T 10357.2-2013 Furniture Mechanical Tests | recommended reference for static-load and stability test method selection. | |
| GB/T 17657-2022 Test Methods for Evaluating the Properties of Wood-Based Panels and Surface Decorated Wood-Based Panels | reference for shelf board only if a production material change replaces metal slats. |
This product must meet the following technical requirements: 1. GB/T 3324-2024 General Technical Requirements for Wooden Furniture: use only as an acceptance reference for dimensional tolerances if wood components are later substituted; current visible product is metal.; 2. GB/T 3325-2017 General Technical Requirements for Metal Furniture: recommended reference for metal-furniture workmanship, coating appearance, and structural acceptance.; 3. GB/T 10357.2-2013 Furniture Mechanical Tests: recommended reference for static-load and stability test method selection.; 4. GB/T 17657-2022 Test Methods for Evaluating the Properties of Wood-Based Panels and Surface Decorated Wood-Based Panels: reference for shelf board only if a production material change replaces metal slats.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
