| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1800 x 900 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge banding thickness | 2 mm | |
| Left storage pedestal dimensions | 450 x 600 x 680 mm | |
| Central knee clearance opening | 750 x 600 x 700 mm | |
| Knee clearance height under desktop | 700 mm | |
| Support panel thickness (desk sides) | 25 mm | |
| Drawer internal dimensions (pedestal box drawer) | 400 x 520 x 120 mm | |
| Desktop overhang (front edge) | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 500 kg | |
|---|---|---|
| Drawer slide rated dynamic load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Net product weight | 140 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E0 grade engineered wood particleboard | |
|---|---|---|
| Desktop surface finish | Matte dark walnut wood grain melamine laminate | |
| Edge banding | 2mm thick matching dark wood PVC edge banding | |
| Structural base panels | 25mm thick matching dark wood engineered wood panels | |
| Storage pedestal drawer fronts | Matching dark wood grain engineered wood panels | |
| Drawer box construction | 12mm thick plywood drawer boxes | |
| Drawer slides | Cold-rolled steel three-section full-extension telescopic slides | |
| Desk base leveling feet | Nylon adjustable height leveling glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Left pedestal storage | 1 top utility drawer for office supplies in left support | |
|---|---|---|
| Cable management | One 60mm diameter cable grommet at desk rear center | |
| Under-desk cable tray | Fixed steel cable tray mounted beneath desktop rear | |
| Leveling adjustment | ±10mm height adjustment via base leveling glides | |
| Drawer extension | Full 100% extension via telescopic steel slides | |
| Work surface layout | Left side storage, central knee well, right solid panel support | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for manager/CEO private workspaces with professional dark wood aesthetic | |
|---|---|---|
| Single user daily office work | Configured for one seated user working with laptop, documents, and office accessories | |
| Corporate office environments | Matches formal commercial office design schemes for director and senior staff workspaces | |
| Home executive office | Appropriate for high-end home office setups requiring integrated storage and professional appearance | |
| Recommended pairing | Pairs with high-back black leather executive office chairs and matching dark wood filing storage | |
| Workstation use case | Supports 8+ hours of daily seated office work including computer tasks and document review |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for commercial desk performance validation | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability requirements for pedestal drawers | |
| EN 14372:2004 | Office furniture surface finish resistance to abrasion and liquid damage |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard covering static load and stability for office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard covering drawer cycle and load requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural stability testing | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E0 grade requirement for indoor office use | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture structural components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural stability testing; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E0 grade requirement for indoor office use; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture structural components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
