Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk x return) | 2400 x 1600 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Knee clearance height under work surface | 680 mm | |
| Knee clearance width (central open bay) | 1200 mm | |
| Side return depth (curved pedestal section) | 700 mm | |
| Edge band thickness | 2 mm | |
| Chrome support leg tube diameter | 50 mm | |
| Cable management grommet inner diameter | 80 mm | |
| Integrated desk pad dimensions | 1800 x 700 mm | |
| Pedestal base footprint (left side) | 800 x 600 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static uniform load capacity | 150 kg | |
|---|---|---|
| Net weight (assembled) | 85 kg | |
| Recommended maximum user weight for seated use | 136 kg | |
| Surface abrasion resistance (melamine top) | 2000 cycles | |
| Leveling foot adjustment range | 10 mm | |
| Product warranty period | 5 years | |
| Available finish color count | 1 (matte white) | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary work surface substrate | E1 grade engineered wood (MFC) | |
|---|---|---|
| Work surface edge treatment | 2mm matte PVC edge banding | |
| Left pedestal construction | Matte white lacquered engineered wood | |
| Right section support legs | Polished chrome-plated steel tube | |
| Integrated work mat | Textured woven anti-slip synthetic leather | |
| Cable management grommet | Matte black ABS plastic | |
| Under-desk support frame | 1.5mm thick powder-coated steel | |
| Adjustable leveling feet | Nylon base with steel threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Flush desktop grommet with under-desk routing channel | |
|---|---|---|
| Support structure configuration | Mixed closed left pedestal and 3-point splayed metal right legs | |
| Integrated work surface mat | Full-width non-slip textured pad across main work zone | |
| Floor leveling adjustment | Threaded adjustable feet on all support points | |
| Desk layout orientation | Fixed left-hand curved return extension | |
| Rounded edge design | Soft rounded corners on all tabletop and pedestal edges | |
| Mounting compatibility | Pre-drilled holes for under-desk cable tray and CPU holder | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Sized for manager/CEO workspace with professional modern aesthetic | |
|---|---|---|
| Home office premium workspace | Sleek low-profile design suitable for high-end residential office setups | |
| Corporate boardroom ancillary workspace | Complements modern minimalist boardroom interiors for auxiliary work use | |
| Seated single-user operation | Optimized for one user with ergonomic knee clearance and large work area | |
| Cable-integrated tech setup | Designed for desktop computers, monitors and office tech with hidden routing |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Safety requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Mechanical safety requirements | |
| EN 12521:2015 | Furniture - Strength, durability and safety for non-domestic tables | |
| EN 71-3:2019 | Migration of certain elements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for safety, durability and structural adequacy | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture Sustainability Standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2016: Office desks and tables; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4897.3-2003: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
