Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2200 x 1800 x 760 mm | |
|---|---|---|
| Main worktop depth | 1000 mm | |
| Worktop thickness | 50 mm | |
| Side return cabinet depth | 600 mm | |
| Side return cabinet height | 650 mm | |
| Knee clearance height | 720 mm | |
| Knee clearance width | 1200 mm | |
| Modesty panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| Steel support leg wall thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Modesty panel cable slot width | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total worktop static distributed load | 300 kg | |
|---|---|---|
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 80000 cycles | |
| Under-desk cable tray load capacity | 10 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Net product weight | 140 kg | |
| Standard commercial warranty | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop core | E0 grade MFC engineered wood | |
|---|---|---|
| Worktop finish | Dark walnut-effect thermally fused melamine | |
| Cabinet and modesty panel core | E1 grade MDF engineered wood | |
| Cabinet finish | Matte dark green scratch-resistant lacquer | |
| Support leg and underframe | Powder-coated dark green steel | |
| Edge banding | 2mm thick impact-resistant PVC | |
| Storage hardware | Cold-rolled steel drawer slides and hinges | |
| Cable grommets | ABS plastic with brush inserts | |
| Cabinet base plinth | 18mm thick engineered wood | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Desktop grommet on return, modesty panel slots, under-desk tray | |
|---|---|---|
| Return cabinet storage | Enclosed door compartment plus two lateral drawers | |
| Fixed worktop height | 760 mm fixed working height | |
| Modesty panel coverage | Full front under-worktop panel | |
| Right-side support structure | Single angled steel leg with underframe cross support | |
| Locking storage option | Central drawer lock secures all storage compartments | |
| Plinth base design | Low-profile closed plinth under return cabinet | |
| Surface resistance | Stain, scald and scratch-resistant worktop finish | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for manager and executive workspaces | |
|---|---|---|
| Senior staff open-plan workstation | Suitable for team leads and senior staff in open offices | |
| Home office premium setup | Ideal for dedicated professional home workspaces | |
| Conference side table setup | Usable as meeting room side work surface for materials | |
| Recommended seating pairing | Matches mid-back to high-back ergonomic executive chairs | |
| Finish compatibility | Coordinates with dark wood and dark green office seating and storage | |
| Cable suitability | Supports dual monitor, laptop and docking station setups |
EU Market Access Requirements* EN Standards
| Office desk safety requirements | EN 527:2011 | |
|---|---|---|
| Office desk stability testing | EN 527:2002+A1:2019 | |
| Formaldehyde emission for panels | EN 13986:2004+A1:2015 |
US and Canada office-furniture standards
| Desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Durability cycle testing | ANSI/BIFMA X2021 | |
| Storage component performance | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Desk dimensional tolerance | GB/T 3326 | |
|---|---|---|
| Worktop surface durability | GB/T 4893.4 | |
| Panel formaldehyde emission | GB 18580 | |
| Hardware durability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Desk dimensional tolerance: GB/T 3326; 2. Worktop surface durability: GB/T 4893.4; 3. Panel formaldehyde emission: GB 18580; 4. Hardware durability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
