Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2600 x 1960 x 760 mm | |
|---|---|---|
| Main desktop thickness | 51 mm | |
| Side return work surface depth | 610 mm | |
| Main work surface depth | 860 mm | |
| Seated knee clearance height | 660 mm | |
| Knee clearance width under main top | 1400 mm | |
| Integrated power grommet diameter | 80 mm | |
| Modesty panel height | 420 mm | |
| Raised main top platform height above lower return surface | 50 mm | |
| Gold accent trim thickness | 2 mm | |
| Edge band thickness on desktop | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 136 kg | |
|---|---|---|
| File drawer dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Limited warranty duration | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | E1-grade engineered wood core with light oak matte laminate finish | |
|---|---|---|
| Storage base panels | E1-grade particleboard core with dark gray matte melamine finish | |
| Decorative accent trim | Gold-toned brushed stainless steel strip | |
| Edge treatment | Matching 2mm PVC edge banding on all desktop and panel edges | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Base support feet | High-impact polypropylene block feet with non-slip pads |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Integrated embedded power grommet with under-desk cable tray | |
|---|---|---|
| Storage configuration | Enclosed fixed pedestal base with lockable file drawer and office supply storage | |
| Work surface layout | Fixed left-side return with stepped two-tier desktop for device and document placement | |
| Privacy feature | Full-height front modesty panel concealing under-desk seated leg area |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Fits manager or director workspaces with professional modern aesthetic | |
|---|---|---|
| Corporate open-plan management station | Provides enclosed storage and integrated power for senior staff work areas |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion for laminate desktop finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static load, durability, and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to dimensional and structural inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to dimensional and structural inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
