Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 1500 x 760 mm | |
|---|---|---|
| Main desktop depth | 760 mm | |
| Side return length | 1200 mm | |
| Desktop thickness | 25 mm | |
| Under-desk knee clearance height | 710 mm | |
| Cable grommet size | 60 mm diameter | |
| Drawer front dimensions | 400 x 200 mm each | |
| CPU compartment internal dimensions | 300 x 500 x 480 mm | |
| Open metal shelf clearance | 300 mm per tier | |
| Side shelf depth | 200 mm | |
| Caster wheel diameter | 50 mm | |
| Steel frame tube diameter | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main desktop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 68 kg | |
| Recommended user weight rating | 136 kg | |
| Surface abrasion resistance | 300 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 25mm E1 grade particle board with concrete-gray thermally fused laminate | |
|---|---|---|
| Support frame | 19-gauge square steel tube with matte black powder-coated finish | |
| Side shelf panels | Diamond-grid expanded steel mesh with matching black powder coat | |
| Drawer cabinet body | 18mm dark gray laminated engineered wood | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Caster wheels | Nylon swivel casters with steel mounting brackets |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Fixed work surface at 760 mm standard office desk height | |
|---|---|---|
| Cable management | Single inset desk grommet for routing power and data cables | |
| Storage configuration | 2 drawers + dedicated CPU compartment + 4 open metal shelves | |
| Mobility | Left return unit fitted with 4 swivel casters for limited repositioning |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Supports single user with laptop/desktop setup and integrated office supply storage | |
|---|---|---|
| Small executive private office | Fits compact office spaces for daily administrative and computer work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial use | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for domestic storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for office work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated drawer and cabinet sections |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture for desk surfaces and cabinetry | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements for steel frame and shelving | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wood panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture for desk surfaces and cabinetry; 2. GB/T 3325-2017: Metal furniture general technical requirements for steel frame and shelving; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wood panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
