Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1800 x 800 x 730 mm | |
|---|---|---|
| Desktop panel thickness | 25 mm | |
| Under-desk knee clearance height | 705 mm | |
| Under-desk knee clearance width | 1600 mm | |
| Metal leg tube wall thickness | 1.2 mm | |
| ABS edge banding thickness | 2 mm | |
| Cable management cutout length | 200 mm | |
| Cable grommet internal diameter | 80 mm | |
| Leg frame width (front to back) | 780 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Net product weight | 47 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Surface heat resistance | 120 °C | |
| Recommended user capacity | 1 person | |
| Floor leveller adjustment range | 10 mm | |
| Product structural warranty | 60 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1-grade high-density particleboard | |
|---|---|---|
| Desktop finish | White matte melamine laminate | |
| Edge protection | 2mm ABS edge banding | |
| Leg frame | Powder-coated carbon steel square tube | |
| Fasteners | Zinc-plated steel screws and brackets | |
| Floor contact pads | Non-slip TPE adjustable levellers | |
| Cable port trim | Black ABS plastic grommet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Cable management cutout | Embedded rectangular port routes monitor/laptop cables off desktop | |
|---|---|---|
| Adjustable floor levellers | Rotating pads adjust height to stabilize desk on uneven floors | |
| Freestanding open frame design | No modesty panel or storage, allows unobstructed leg and chair movement | |
| Scratch-resistant work surface | Melamine finish resists scuffs from office equipment and writing tools | |
| Flat-pack assembly | Knock-down construction with pre-drilled holes for on-site assembly | |
| Smooth edge profile | Rounded safety edges eliminate sharp contact points at desk perimeter | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Provides large clean work surface for managerial daily work and meetings | |
|---|---|---|
| Home office workstation | Minimalist design fits modern residential interiors, supports computer and document work | |
| Open-plan work area | Freestanding design works as individual workstation in co-working or office spaces | |
| Small conference breakout space | Long surface supports 3people for quick informal meetings | |
| Design studio workspace | Smooth white surface supports drawing, laptop work and layout of design materials |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial use evaluation | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and structural requirements, aligns with seated work height standards | |
| EN 13722:2004 | Furniture edge and surface durability requirements, applies to melamine finish performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, reference for load and stability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, reference for material emission and recycled content criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk top and structural assembly | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks, applies to load, stability and dimensional tolerance | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood, applies to desktop substrate compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk top and structural assembly; 2. GB/T 3327-2016: Performance requirements for office desks, applies to load, stability and dimensional tolerance; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood, applies to desktop substrate compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
