Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 2000 x 760 mm | |
|---|---|---|
| Main work surface width | 1800 mm | |
| Perforated modesty panel height | 350 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Main desktop static load capacity | 159 kg | |
|---|---|---|
| Drawer slide rated load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet doors | 80000 cycles | |
| Melamine finish abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 30 mm E1 grade particleboard with light grey melamine laminate finish, 2 mm PVC edge banding | |
|---|---|---|
| Side storage cabinet body | 18 mm E1 grade particleboard with dark charcoal grey melamine laminate finish | |
| Support legs | 40 x 40 mm tapered steel tube with 1.5 mm wall thickness, matte black powder-coated finish | |
| Modesty panel | 1.2 mm thick perforated steel sheet, matte black powder-coated finish | |
| Leveling feet | Nylon reinforced adjustable floor glides fitted to all leg bases | |
| Cable grommets | 60 mm diameter ABS plastic cable pass-throughs at work surface junction | |
| Internal drawer components | 0.8 mm cold-rolled steel drawer boxes with full-extension ball bearing slides | |
| Hardware fasteners | Zinc-plated steel connector bolts and cam locks for flat-pack assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Perforated modesty panel with 4 lower cable slots routes peripheral cables to under-desk cable tray, 60 mm pass-through at return junction | |
|---|---|---|
| Storage configuration | Enclosed side credenza includes 2 utility drawers and 1 hanging file drawer for A4/legal documents, with soft-close mechanisms | |
| Floor leveling | Adjustable nylon glides on all legs compensate for 15 mm of floor unevenness without tools | |
| Static work surface | Fixed-height desktop at 760 mm provides standard ergonomic seated work position, no height adjustment mechanism | |
| Knee space access | 1200 mm wide open knee bay under main work surface accommodates standard office chair swivel and leg movement | |
| Modesty privacy | 350 mm tall perforated front panel blocks direct view of under-desk cabling and user legs while allowing air flow | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fixed L-layout supports primary monitor work on main surface and printer/meeting materials on side return for manager use | |
|---|---|---|
| Open-plan senior workstation | Two-tone finish matches modern office interiors, perforated panel provides leg privacy without blocking ventilation | |
| Home executive office | Enclosed storage hides office supplies to maintain clean residential aesthetic, 760 mm height pairs with standard ergonomic office chairs | |
| Small meeting room side work surface | Provides auxiliary writing and document prep space adjacent to conference tables for meeting facilitators | |
| Hybrid work management office | Integrated cable management supports docking station, monitor, and video conferencing peripheral setup without cable clutter |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for panel substrate and finish quality acceptance | |
|---|---|---|
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood-based panels | Applicable for E1 grade substrate formaldehyde emission verification | |
| GB/T 3327-2016 Office desks and tables | Applicable for structural strength, dimensional stability, and safety performance acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for panel substrate and finish quality acceptance; 2. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood-based panels: Applicable for E1 grade substrate formaldehyde emission verification; 3. GB/T 3327-2016 Office desks and tables: Applicable for structural strength, dimensional stability, and safety performance acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
