Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Net product weight | 135 kg | |
| Seating capacity | 1 person | |
| Edge impact resistance | 120 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | Dark walnut wood-grain melamine faced particleboard | |
|---|---|---|
| Cabinet body panels | Matte dark gray melamine faced MDF | |
| Decorative accents | Brushed gold-tone PVC edge trim | |
| Base plinth | Black PVC wrapped engineered wood | |
| Cable grommet cover | Matte black ABS plastic | |
| Internal drawer slides | Cold-rolled steel ball-bearing slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed desktop grommet routes cables to under-desk channel | |
|---|---|---|
| Storage pedestal | Left-side enclosed cabinet provides lockable file and supply storage | |
| Ventilation design | Horizontal slotted vents on cabinet side for computer host heat dissipation | |
| Assembly type | Knock-down assembly with cam-lock hardware connections |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive offices | Provides spacious work surface and integrated storage for senior management workspaces | |
|---|---|---|
| Manager work rooms | Offers dedicated file storage and cable management for daily administrative and computer work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial office furniture | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables, dimensional requirements for ergonomic seated use | |
| EN 13722:2004 | Furniture, test methods for surface resistance to abrasion and impact for desk tops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, defining load, stability and durability performance requirements |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desks | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for wooden desks and tables, applicable for load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required E1 grade for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desks; 2. GB/T 3327-2017: Performance test methods for wooden desks and tables, applicable for load and stability testing; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required E1 grade for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
