Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 2000 x 760 mm | |
|---|---|---|
| Main desktop thickness | 50 mm | |
| Main desktop depth | 1100 mm | |
| Right side pedestal width | 600 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1600 mm | |
| Cable grommet diameter | 80 mm | |
| Modesty panel height | 450 mm | |
| Decorative edge trim width | 30 mm | |
| Pedestal drawer interior depth | 500 mm | |
| Edge banding thickness | 2 mm | |
| Pedestal base plinth height | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | High-density fiberboard (HDF) | |
|---|---|---|
| Desktop surface | Natural wood veneer with matte polyurethane lacquer | |
| Side support panels | MDF substrate with dark matte lacquer finish | |
| Decorative trim | Engraved solid wood with matching dark lacquer | |
| Pedestal door panel | MDF with inlaid wood geometric lattice overlay | |
| Drawer slides | Cold-rolled steel with soft-close mechanism | |
| Edge banding | 2mm thick ABS matching wood veneer finish | |
| Cable grommet | Brushed zinc alloy with flip cover | |
| Leveling feet | Nylon-padded steel adjustable feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Desktop grommet routes power/data cables to under-desk tray | |
|---|---|---|
| Right pedestal storage | Fixed cabinet with 2 file drawers and 1 lockable door | |
| Locking system | Centralized lock secures all pedestal drawers and door | |
| Knee clearance access | Open central well allows unobstructed seated leg movement | |
| Surface maintenance | Stain-resistant lacquer finish allows cleaning with standard office cleaners | |
| Floor leveling | Adjustable feet correct minor unevenness in office flooring | |
| Modesty coverage | Front modesty panel blocks view of seated user's legs from front | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 30sqm CEO/executive office spaces for daily management work | |
|---|---|---|
| Corporate leadership workspace | Suits director, general manager and senior leadership office layouts | |
| High-end commercial office | Appropriate for Class A office building executive floor installations | |
| Paired furniture set | Coordinates with matching high-back executive chairs and filing cabinets | |
| Formal meeting preparation use | Supports document review, laptop work and small in-office meetings | |
| Recommended seating position | Centered at main desk front facing the office entry |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for office work desk dimensions and safety requirements | |
|---|---|---|
| EN 527-2:2016 | Applicable for office desk mechanical stability and strength requirements | |
| EN 13722:2004 | Applicable for office furniture storage unit performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products performance testing and safety | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for office storage units performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB/T 3327-2019 | Applicable for office desk and table performance and stability requirements | |
| GB 18580-2017 | Applicable for formaldehyde emission limits for wood-based panel products |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB/T 3327-2019: Applicable for office desk and table performance and stability requirements; 3. GB 18580-2017: Applicable for formaldehyde emission limits for wood-based panel products; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
