Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 1800 x 790 mm | |
|---|---|---|
| Main work surface depth | 900 mm | |
| Side return depth | 500 mm | |
| Desk top thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height | 690 mm | |
| Knee clearance width | 800 mm | |
| Side panel thickness | 25 mm | |
| Drawer internal height (utility drawer) | 120 mm | |
| Drawer internal height (file drawer) | 250 mm | |
| CPU compartment internal dimensions | 300 x 500 x 450 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desk top static load capacity | 227 kg | |
|---|---|---|
| Recommended user capacity | 1 person | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 90 kg | |
| Commercial warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | High-gloss laminate over 50mm MDF core | |
|---|---|---|
| Structural side panels | 25mm particle board with melamine finish | |
| Drawer boxes | 18mm engineered wood with PVC edge banding | |
| Drawer slides | Cold-rolled steel 3-section full-extension slides | |
| Drawer lock | Zinc alloy keyed cam lock | |
| Door hinges | Cold-rolled steel concealed hinges | |
| CPU compartment shelf | 18mm engineered wood fixed shelf | |
| Cable grommets | ABS plastic with brush insert | |
| Leveling feet | Nylon adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management | Two 80mm grommets route cords from top to under-desk space | |
|---|---|---|
| Locking drawer storage | Keyed lock secures top utility and lower file drawer | |
| Dedicated CPU storage | Open ventilated compartment under side return holds full-size tower | |
| Closed side cabinet storage | Single hinged door cabinet for bulk office supply storage | |
| Overhanging work edge | 50mm front overhang allows comfortable arm resting | |
| Leveling adjustment | Adjustable nylon feet compensate for uneven floor surfaces | |
| Non-reversible return layout | Fixed left-side storage return for fixed corner placement | |
| Scratch-resistant work surface | Glossy laminate surface resists scuffs from office equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for manager or senior staff daily workstation | |
|---|---|---|
| Home office workspace | Suitable for dedicated home executive work setups | |
| Small meeting room corner | Functions as a small conference workstation for 2visitors | |
| Open office manager pod | Used as semi-private manager station in open plan layouts | |
| Consulting office space | Suitable for advisor or client meeting work area |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for domestic/office tables | |
| EN 717-1:2004 | Formaldehyde emission classification for wood panels |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Furniture mechanical test for table strength and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 10357.1-2013: Furniture mechanical test for table strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
