Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1600 x 760 mm | |
|---|---|---|
| Worktop thickness | 25 mm | |
| Main work surface depth | 850 mm | |
| Side return depth | 600 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet opening size | 80 mm | |
| Support leg tube wall thickness | 1.5 mm | |
| Drawer front panel thickness | 18 mm | |
| Modesty panel height | 350 mm | |
| Storage cabinet interior shelf height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 65 kg | |
|---|---|---|
| Worktop static load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 revolutions | |
| Recommended user count | 1 | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop | E1-grade melamine-faced particle board with walnut wood-grain finish | |
|---|---|---|
| Storage cabinet panels | E1-grade melamine-faced MDF with dark gray matte finish | |
| Angled support leg | Powder-coated dark gray steel with 2x split prong design | |
| Drawer slides | Cold-rolled steel with zinc-plated corrosion-resistant finish | |
| Cabinet hinges | Stainless steel hydraulic soft-close hinges | |
| Edge banding | 2mm thick PVC edge banding matching worktop and cabinet colors | |
| Modesty panel | 18mm thick melamine-faced particle board with dark gray finish | |
| Cable grommet | ABS plastic with brush insert for cable pass-through | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Recessed cable grommet with brush insert routes power and data cables from work surface to floor | |
|---|---|---|
| Drawer storage | Two front-mounted soft-close drawers provide lockable storage for office supplies | |
| Side return cabinet | Closed rear storage cabinet with adjustable shelf accommodates files and office equipment | |
| Modesty panel | Suspended front panel blocks direct view of seated user's lap for privacy | |
| Support structure | Single angled split-prong steel leg at free end and cabinet pedestal at return end eliminate knee obstruction | |
| Surface protection | Scratch, water, and stain-resistant melamine finish supports daily office use without premature wear | |
| Return orientation | Factory-configured fixed right-side return optimized for executive office layout | |
| Assembly structure | Knock-down flat-pack construction with cam-lock fasteners for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits standard manager office footprints for daily executive work and document storage | |
|---|---|---|
| Home office workspace | Works in dedicated home office spaces for remote professionals needing organizational storage | |
| Small meeting room | Serves as a presentation or small collaboration surface for 3 meeting participants | |
| Manager workstations in open plan | Can be used as partitioned manager stations in open-plan office environments | |
| Recommended pairing | Pairs with mid-back executive office chairs with 650 mm seat height for ergonomic fit | |
| Finish suitability | Walnut and dark gray finish coordinates with modern commercial office furniture palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional requirements, applicable to work height and stability | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety requirements, applicable to load capacity and stability | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer and cabinet performance | |
| EN 14074:2004 | Office furniture movable components durability requirements, applicable to slides and hinges |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability, and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer load and cycle performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet construction | |
|---|---|---|
| GB/T 3327-2016 | Dimensions and tolerance requirements for office desks, applicable to work height and clearance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade board material | |
| GB/T 4897.3-2003 | Particle board specification for furniture use, applicable to worktop and panel materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet construction; 2. GB/T 3327-2016: Dimensions and tolerance requirements for office desks, applicable to work height and clearance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade board material; 4. GB/T 4897.3-2003: Particle board specification for furniture use, applicable to worktop and panel materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
