Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2000 x 1600 x 750 mm | |
|---|---|---|
| Main desktop work surface | 1800 x 700 mm | |
| Left return storage cabinet | 1400 x 600 x 700 mm | |
| Desktop thickness | 30 mm | |
| Knee clearance height under main desk | 650 mm | |
| Knee clearance width between return and leg | 1200 mm | |
| Suspended front drawer unit height | 250 mm | |
| Integrated power/data grommet | 80 mm diameter | |
| Metal support leg cross-section | 50 x 50 mm | |
| Edge banding thickness | 2 mm | |
| Return cabinet internal shelf clearance | 320 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 180 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight limit | 150 kg | |
| Adjustable foot leveling range | 10 mm | |
| Drawer slide cycle rating | 50000 cycles | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main desktop | E1 grade particleboard core with light oak thermally fused melamine laminate | |
|---|---|---|
| Storage cabinet panels | E1 grade MDF core with matte dark green powder paint finish | |
| End support legs | 1.5mm thick square carbon steel tube with matte dark green powder coating | |
| Desk edge banding | 2mm thick impact-resistant dark green PVC edging | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Drawer pulls | Recessed matte silver ABS integrated handles | |
| Cable grommet | ABS plastic dual-port power/data grommet with matte black finish | |
| Leveling feet | Reinforced nylon adjustable feet with steel threaded inserts | |
| Internal cabinet shelves | 18mm thick E1 grade particleboard with matching dark green laminate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | 80mm dual-port desktop grommet routes power and data cables to floor | |
|---|---|---|
| Front suspended drawers | Two full-width drawers with ball-bearing slides for stationery and file storage | |
| Left return cabinet | Enclosed multi-shelf storage cabinet with fixed shelves for office supplies | |
| Leveling adjustment | Threaded adjustable feet at leg and cabinet base compensate for uneven floors | |
| Work surface layout | Left return provides secondary work/prep surface adjacent to main desk | |
| Modesty panel function | Solid drawer front panel blocks leg visibility from desk front | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for manager/CEO individual work with integrated storage and large work surface | |
|---|---|---|
| Home office workspace | Fits dedicated home office rooms for professional remote work use | |
| Small meeting breakout space | Functions as a compact meeting surface for 3person quick discussions | |
| Corporate open plan manager workstation | Provides dedicated personal storage and work area in open office layouts | |
| Reception back office | Supports administrative staff work with adjacent storage for office supplies |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to fixed executive desks | |
|---|---|---|
| EN 15372:2016 | Furniture strength durability and safety for non-domestic office tables | |
| EN 14372:2004 | Furniture hardware drawer slide performance requirements for office storage |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance requirements for integrated desk cabinets and drawers |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel desk construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade board selection | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable to desktop core material | |
| GB/T 13668-2015 | Steel office furniture general requirements, applicable to powder-coated metal legs |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel desk construction; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade board selection; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable to desktop core material; 4. GB/T 13668-2015: Steel office furniture general requirements, applicable to powder-coated metal legs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
