| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 2200 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Main desktop depth | 900 mm | |
| Side return credenza length | 1800 mm | |
| Side return credenza depth | 600 mm | |
| Knee clearance height under desktop | 650 mm | |
| Knee clearance width between supports | 700 mm | |
| Structural side panel thickness | 60 mm | |
| Modesty panel slat thickness | 15 mm | |
| Marble accent panel thickness | 18 mm | |
| PVC edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 500 kg | |
|---|---|---|
| Side return work surface static load | 300 kg | |
| Drawer slide rated load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet doors | 100000 cycles | |
| Surface scratch resistance rating | 2 N | |
| Surface heat resistance | 80 °C | |
| Recommended maximum user weight for seating | 150 kg | |
| Product net weight | 120 kg | |
| Standard warranty period | 5 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E0-grade high-density MDF core | |
|---|---|---|
| Desktop surface finish | Dark walnut wood veneer with matte lacquer topcoat | |
| Decorative accent panels | Dark grey marble-look engineered stone veneer | |
| Modesty grille slats | Solid hardwood slats with dark brown powder-coated finish | |
| Base and side cabinet panels | E0-grade melamine-faced chipboard | |
| Edge banding | 2mm thick PVC edge banding with color match | |
| Structural connectors | Zinc-plated steel two-in-one quick-assembly fittings | |
| Cable management components | ABS plastic grommets and under-desk steel cable tray | |
| Drawer hardware | Cold-rolled steel ball-bearing full-extension slides | |
| Door hinges | Cold-rolled steel hydraulic soft-close hinges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Work surface layout | Fixed L-shaped configuration with left-side return credenza | |
|---|---|---|
| Front privacy barrier | Full-width vertical slat modesty panel between desktop and floor | |
| Cable management system | Dual desktop grommets with under-desk routed cable channels | |
| Storage configuration | Concealed cabinet storage within side return and right support base | |
| Locking storage | Integrated keyed lock for central file drawer compartment | |
| Surface assembly | Knocked-down flat-pack construction with cam-lock connectors | |
| Adjustable feet | 12mm height-adjustable glide feet on base bottom | |
| Return orientation | Fixed left-side return as pictured, reversible option available for custom orders | |
| Knee clearance access | Open central knee bay with no cross-braces blocking leg movement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for director, CEO or senior manager private workspace | |
|---|---|---|
| Corporate management suite | Suitable for paired matching file cabinet and executive chair as shown | |
| Home office luxury setup | Appropriate for high-end residential workspaces requiring professional storage | |
| Boardroom adjunct office | Usable as meeting preparation desk adjacent to conference spaces | |
| Formal reception manager office | Suitable for front-of-house management workstations with visitor-facing front | |
| Recommended configuration | Pair with matching high-back leather executive chair and lateral file bookcase |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for desktop load and stability testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety requirements, applicable for knee clearance and edge specifications | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion, applicable for desktop finish durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load, stability and durability performance testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and recyclability criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel dimensional stability and finish adhesion | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E0 grade ≤0.05mg/m³ required for indoor office use | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applicable for structural cabinet panel substrate | |
| GB/T 11718-2009 | Medium density fiberboard specification, applicable for desktop core material performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel dimensional stability and finish adhesion; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E0 grade ≤0.05mg/m³ required for indoor office use; 3. GB/T 4897.3-2015: Particleboard specification for furniture use, applicable for structural cabinet panel substrate; 4. GB/T 11718-2009: Medium density fiberboard specification, applicable for desktop core material performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
