Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1800 x 1600 x 1290 mm | |
|---|---|---|
| Main worktop depth | 700 mm | |
| Side credenza height | 750 mm | |
| Side credenza open shelf compartment dimensions | 600 x 400 x 300 mm | |
| Seated knee clearance height | 700 mm | |
| Seated knee clearance width | 800 mm | |
| Worktop panel thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| T-shaped lift leg column diameter | 80 mm | |
| T-leg base foot length | 700 mm | |
| Credenza cabinet door panel thickness | 18 mm | |
| Cable grommet diameter | 60 mm | |
| Open shelf adjustable layer spacing | 320 mm | |
| Minimum desk height (seated position) | 640 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Total static lifting load capacity | 225 kg | |
|---|---|---|
| Drawer slide static load rating | 35 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Cabinet hinge cycle durability | 100000 cycles | |
| Motor lift cycle rating | 20000 cycles | |
| Lift operation noise level | 50 dB | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Net product weight | 120 kg | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop | 25mm thick particleboard core with light oak melamine finish | |
|---|---|---|
| Height adjustment leg and base | 1.5mm thick white powder-coated cold-rolled steel | |
| Edge banding | 2mm thick impact-resistant PVC matching worktop finish | |
| Credenza cabinet carcass | 18mm thick particleboard with matching light oak melamine laminate | |
| Open shelf interior panels | 18mm thick particleboard with matte grey melamine finish | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges | |
| Drawer slides | Zinc-plated cold-rolled steel full-extension ball-bearing slides | |
| Lift column internal components | Hardened steel telescoping segments with self-lubricating nylon glides | |
| Cable grommets | ABS plastic with removable brush insert | |
| Adjustable feet on credenza base | Nylon and steel height-adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Electric height adjustment | Three-segment telescoping column adjusts 1290 mm via push-button controller | |
|---|---|---|
| Memory height presets | 4 programmable height positions stored on digital controller | |
| Anti-collision protection | Obstacle detection reverses lift direction if resistance is detected | |
| Mixed credenza storage | 2 open adjustable shelves, 2 closed cabinet doors, 1 lower drawer | |
| Integrated cable management | 60mm worktop grommet and under-desk cable tray route power/data cables | |
| Soft-close cabinet hardware | Hinges and drawer slides include soft-close damping | |
| Adjustable shelf positions | Open credenza shelves support 3 height positions via metal shelf pins | |
| Child lock function | Controller lock disables height adjustment to prevent unintended operation | |
| Overheat protection for motor | Automatic motor shutoff after continuous 2 minutes of operation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Provides integrated work and storage for single-user executive workspaces | |
|---|---|---|
| Home office workspace | Sit-stand adjustment supports long work sessions with ergonomic position changes | |
| Manager workstation in open plan office | Integrated credenza stores documents and personal items without additional furniture | |
| Small business administrative office | Combines work surface and storage in one footprint to reduce furniture clutter | |
| Recommended paired furniture | Ergonomic mesh office chair, monitor arm, CPU holder, and under-desk power strip | |
| Small conference/meeting workspace | Side credenza provides surface for meeting materials and equipment storage |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office work desk safety, strength, and stability requirements for height-adjustable models | |
|---|---|---|
| EN 527-2:2016 | Applies to dimensional, ergonomic, and adjustment performance requirements for office desks | |
| EN 15372:2016 | Applies to durability, strength, and safety requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products static, dynamic, and cyclic load performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to storage cabinet strength, durability, and stability testing for office use | |
| ANSI/BIFMA X5.15-2018 | Applies to electrical safety and functional performance of height-adjustable desks |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, stability, and strength requirements for commercial use | |
|---|---|---|
| GB/T 3327-2016 | Applies to office storage cabinet strength, durability, and dimensional tolerances | |
| GB/T 24821-2009 | Applies to office worktop surface performance, including abrasion and heat resistance | |
| GB/T 24977-2010 | Applies to electrical safety requirements for motorized height-adjustable office furniture |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, stability, and strength requirements for commercial use; 2. GB/T 3327-2016: Applies to office storage cabinet strength, durability, and dimensional tolerances; 3. GB/T 24821-2009: Applies to office worktop surface performance, including abrasion and heat resistance; 4. GB/T 24977-2010: Applies to electrical safety requirements for motorized height-adjustable office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
