Automatic mm / inch conversion · Core engineering specifications
| overall L-shaped dimensions | 2000 x 1800 x 760 mm | |
|---|---|---|
| main work surface size | 2000 x 900 mm | |
| left side return size | 1200 x 500 mm | |
| tabletop thickness | 50 mm | |
| knee clearance height under main desk | 650 mm | |
| knee clearance width under main desk | 1600 mm | |
| modesty panel height | 600 mm | |
| decorative inlay trim thickness | 2 mm | |
| cable grommet diameter | 60 mm | |
| support leg cross-section | 100 x 100 mm | |
| edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| tabletop static load capacity | 150 kg | |
|---|---|---|
| drawer slide dynamic load per drawer | 25 kg | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| net product weight | 117 kg | |
| recommended user capacity | 1 person | |
| surface abrasion resistance rating | 2000 cycles | |
| product warranty | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desk substrate | E1 grade MDF engineered wood | |
|---|---|---|
| main desk surface finish | Walnut wood grain veneer or thermally fused laminate | |
| side return front panel | Cream matte laminate | |
| edge trim | Solid wood edge banding with thin light inlay | |
| modesty panel core | 18 mm thick MDF panel | |
| support leg construction | Panel-constructed engineered wood legs | |
| cable grommet | ABS plastic | |
| drawer and cabinet hardware | Cold-rolled steel slides and concealed hinges | |
| surface coating | Eco-friendly UV cured lacquer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| fixed work height position | 760 mm work surface aligned to standard ergonomic seated office height | |
|---|---|---|
| cable management system | 60 mm side return grommet with under-desk routing channel | |
| side return storage configuration | 3 soft-close drawers plus 1 closed door cabinet | |
| front privacy modesty panel | Full-height solid panel blocking direct view of seated leg area | |
| drawer operation | Full extension ball-bearing slides with soft-close damping | |
| cabinet door operation | Concealed hinges with 110 degree opening angle | |
| surface load distribution | Reinforced under-top support frame spanning main work surface | |
| floor contact protection | Adjustable leveling glides at all leg bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| executive private office | Suitable for manager or director private offices in corporate headquarters | |
|---|---|---|
| home executive workspace | Appropriate for high-end home office use with integrated storage | |
| corporate meeting rooms | Usable as a meeting table for small 3person in-office discussions | |
| recommended paired furniture | Compatible with high-back executive office chairs and matching wood bookcases | |
| equipment suitability | Supports all-in-one computers, monitor setups, and standard office peripherals | |
| floor type compatibility | Suitable for low-pile carpet, polished tile, and engineered wood office flooring |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance checks | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability requirements for storage units, applicable to return cabinet checks | |
| EN 71-3:2019 | Migration of certain elements for furniture surfaces, required for low-VOC material acceptance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for cabinet and drawer performance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for E1 grade material acceptance | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture coatings, applicable to finish durability checks | |
| GB/T 10357.1-1989 | Furniture table mechanical stability test standard, required for structural safety verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required for E1 grade material acceptance; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture coatings, applicable to finish durability checks; 4. GB/T 10357.1-1989: Furniture table mechanical stability test standard, required for structural safety verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
