| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Maximum desktop static load capacity | 120 kg | |
|---|---|---|
| Total product net weight | 115 kg | |
| Maximum seated user weight allowance | 150 kg | |
| Height adjustment speed | 38 mm/s | |
| Lifting cycle durability rating | 10000 cycles | |
| Desktop surface abrasion resistance | 2000 revolutions | |
| Side cabinet drawer static load | 25 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E0-grade particleboard core | |
|---|---|---|
| Desktop surface | Walnut wood-grain melamine laminate | |
| Lifting columns | 1.5mm thick powder-coated matte black steel | |
| Side cabinet panels | Two-tone melamine particleboard | |
| Desk edge banding | 2mm thick PVC impact-resistant edge banding | |
| Support feet | 2mm thick folded steel with anti-slip rubber pads | |
| Cabinet drawer hardware | Cold-rolled steel drawer slides | |
| Lifting mechanism crossbeam | 2mm thick rectangular steel crossbeam | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Electric height adjustment | Dual-motor drive adjusts from seated to standing height | |
|---|---|---|
| Memory height presets | 3 programmable height positions stored on control panel | |
| Integrated side storage | Combines lockable drawer and two open shelves | |
| Anti-collision protection | Automatic stop when obstacle is detected during travel | |
| Cable management channel | Recessed under-desk cable tray along desktop apron | |
| Lockable storage drawer | Single key-locked drawer for secure document storage | |
| Leveling adjustment feet | Adjustable glides on side cabinet base | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipping gross weight | 135 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suits senior management offices for extended seated and standing work | |
|---|---|---|
| Standing-sit workstation | Supports alternating posture throughout the workday to reduce sedentary fatigue | |
| Mid-sized open office team space | Provides sufficient work area and storage for supervisor workstations | |
| Small home executive office | Combines work surface and storage to minimize footprint in home workspaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office work desk safety and dimensional requirements | |
|---|---|---|
| EN 527-2:2016 | Applies to height-adjustable desk mechanical safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products performance and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, strength and durability requirements | |
|---|---|---|
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Applies to desk mechanical performance test methods |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, strength and durability requirements; 2. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panels; 3. GB/T 10357.1-2013: Applies to desk mechanical performance test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
