Automatic mm / inch conversion · Core engineering specifications
| overall L-shaped footprint | 2000 x 1800 x 1220 mm | |
|---|---|---|
| main work surface depth | 800 mm | |
| desktop thickness | 64 mm | |
| edge banding thickness | 2 mm | |
| minimum desktop height (seated) | 760 mm | |
| maximum desktop height (standing) | 1220 mm | |
| seated knee clearance height | 680 mm | |
| knee clearance width | 1200 mm | |
| left return cabinet width | 600 mm | |
| left return cabinet depth | 1600 mm | |
| modesty panel height | 400 mm | |
| steel leg upright section size | 80 x 50 mm | |
| steel leg base foot length | 700 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| net product weight | 95 kg | |
|---|---|---|
| desktop static load capacity | 125 kg | |
| adjustment lifting speed | 40 mm/s | |
| drawer slide static load rating | 45 kg | |
| drawer slide cycle rating | 50000 cycles | |
| hinge open/close cycle rating | 100000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop core | High-density MDF substrate | |
|---|---|---|
| desktop surface | Dark walnut wood veneer finish | |
| return cabinet panels | Matte grey melamine-faced engineered wood | |
| edge detailing | 2mm thick impact-resistant PVC edge banding | |
| height-adjustable legs | Powder-coated cold-rolled steel | |
| modesty panel | Matte grey MDF panel with metal mounting brackets | |
| drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| hinge hardware | Zinc-plated steel soft-close cabinet hinges | |
| cable management parts | ABS plastic grommets and steel under-desk cable tray | |
| leveling glides | Nylon base adjustable feet on leg bottoms | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| height adjustment mechanism | Electric dual-column lift with push-button control, 460mm total travel | |
|---|---|---|
| height memory presets | 4 programmable height positions stored in control panel | |
| anti-collision protection | Built-in impact sensor stops and reverses lift on obstruction | |
| storage pedestal layout | Left-side return with 3 lockable drawers, including 1 hanging file drawer | |
| modesty panel design | Telescoping privacy panel that moves with desktop height adjustment | |
| cable management system | 3 desktop cable grommets plus under-desk routed cable channel | |
| drawer operation | Full-extension soft-close drawers with integrated lock | |
| leveling adjustment | ±15mm height adjustment on each leg foot | |
| charging port integration | Embedded AC/USB charging port on desktop surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Designed for senior management private offices in corporate headquarters | |
|---|---|---|
| sit-stand work configuration | Supports alternating seated and standing work postures throughout the day | |
| open-plan manager workstation | Suitable for partitioned open-plan manager work areas | |
| high-rise city view offices | Complements modern high-rise office interiors with floor-to-ceiling windows | |
| corporate boardroom ancillary workspace | Can be used as a dedicated working surface in boardroom anterooms | |
| 1-user dedicated workstation | Designed for single-user executive use with integrated file storage |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables - Safety, strength and durability requirements | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for office storage units | |
| EN 717-1:2004 | Wood-based panels - Formaldehyde emission determination |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard | |
| ANSI/BIFMA G1-2013 | Ergonomic guidelines for adjustable office furniture |
Standards applicable to China-market projects
| GB/T 3326-2016 | Desk, chair and bench size standard for office furniture | |
|---|---|---|
| GB/T 3327-2016 | Office furniture cabinet mechanical performance requirements | |
| GB/T 35607-2017 | Green product assessment standard for furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Desk, chair and bench size standard for office furniture; 2. GB/T 3327-2016: Office furniture cabinet mechanical performance requirements; 3. GB/T 35607-2017: Green product assessment standard for furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
