Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2000 x 1800 x 750 mm | |
|---|---|---|
| Main work surface dimensions | 1800 x 800 mm | |
| Left return cabinet dimensions | 1200 x 500 x 650 mm | |
| Worktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Under-desk knee clearance height | 670 mm | |
| Knee clearance width (central bay) | 1200 mm | |
| Modesty panel dimensions | 1400 x 400 x 20 mm | |
| Cable grommet dimensions | 300 x 80 mm | |
| Steel leg section size | 60 x 30 mm | |
| Leveler foot adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk net weight | 93 kg | |
|---|---|---|
| Worktop static load capacity | 136 kg | |
| Drawer slide dynamic load rating | 25 kg per drawer | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Cabinet door hinge cycle durability | 80000 open/close cycles | |
| Recommended maximum user weight (seated use) | 136 kg | |
| Surface abrasion resistance | 2000 revolutions | |
| Standard commercial product warranty | 10 years for frame/top, 5 years for hardware | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core and finish | 25mm particleboard core with 25mm build-up, white melamine laminate facing | |
|---|---|---|
| Return cabinet body | 18mm melamine-faced chipboard (MFC) with matching white edge banding | |
| Cantilever U-legs | 1.5mm thick powder-coated steel, silver/white matte finish | |
| Front modesty panel | 20mm thick melamine-coated particleboard, light grey finish | |
| Drawer and cabinet hardware | Steel keyed cam locks, three-quarter extension ball-bearing slides, concealed hinges | |
| Leveler feet | Reinforced nylon base with steel threaded stem, black non-slip pad | |
| Cable grommet trim | Black ABS plastic bezel for rectangular cable cutout | |
| Frame connection hardware | Steel-to-steel bolted fixings with anti-loosening washers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management | Rectangular recessed grommet routes power/data cables from worktop to under-desk area | |
|---|---|---|
| Lockable storage pedestal | Left fixed return includes 2 lockable drawers and 1 enclosed cabinet bay | |
| Cantilever frame support | Open U-shaped steel legs eliminate front cross-braces to maximize leg room | |
| Floor leveling adjustment | Threaded glide feet adjust up to 15mm to compensate for uneven floor surfaces | |
| Seated privacy modesty panel | Full-width front panel blocks view of user legs from office front approach | |
| Work surface edge treatment | Rounded 2mm PVC edge banding protects users from sharp corners and impact damage | |
| Fixed height work surface | 750mm standard office work height aligns with ergonomic task chair adjustment ranges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for manager and director private workspaces requiring integrated storage | |
|---|---|---|
| Open-plan manager workstation | Works in semi-enclosed office zones with modesty panel for user privacy | |
| Small business meeting office | Supports small in-desk meetings with space for 2 guest chairs opposite user | |
| Home office professional setup | Suitable for remote professional home offices requiring commercial-grade durability | |
| Recommended seating pairing | Pair with mid-back or high-back executive task chair with 520 mm seat height adjustment | |
| Finish compatibility | White and light grey finish coordinates with modern light-toned or monochrome office interiors |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Part 1: Dimensions, applicable to work height and clearance compliance | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables – Part 2: Mechanical safety requirements, applicable to strength and stability | |
| EN 13501-1:2018 | Fire classification of construction products, applicable to panel material fire performance rating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products – Tests for safety, durability, and structural performance for office use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability and finish quality | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applicable to worktop load and stability verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability and finish quality; 2. GB/T 3327-2016: Performance test methods for office desks, applicable to worktop load and stability verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
