Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 2000 x 900 x 750 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| ABS edge band thickness | 2 mm | |
| Knee clearance height under desk | 670 mm | |
| Knee clearance width between side panels | 1200 mm | |
| Cable grommet diameter | 60 mm | |
| Modesty panel thickness | 18 mm | |
| Side support panel thickness | 36 mm | |
| Matching 3-drawer mobile pedestal dimensions | 425 x 600 x 653 mm | |
| Desktop overhang at front edge | 50 mm | |
| Floor clearance under base panels | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 25 kg | |
| Drawer slide cycle life | 50000 open/close cycles | |
| Hinge cycle life for cabinet doors | 80000 open/close cycles | |
| Desk net weight | 115 kg | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Material formaldehyde emission class | E1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | High-density particleboard | |
|---|---|---|
| Desktop surface | Walnut wood grain melamine veneer | |
| Front modesty panel | Dark walnut engineered wood panel | |
| Side support panels | Matte grey lacquered MDF panels | |
| Edge banding | 2mm thick rounded ABS edging | |
| Cable grommets | Matte black plastic grommets | |
| Leveling feet | 10mm adjustable nylon glides | |
| Drawer slides | Cold-rolled steel ball-bearing slides | |
| Panel fasteners | Zinc-plated steel cam lock connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Two pre-installed 60mm desktop grommets route power/data cables | |
|---|---|---|
| Leveling adjustment | Base glides adjust 10mm to stabilize desk on uneven floors | |
| Storage compatibility | Pairs with 3-drawer mobile pedestal on braked casters | |
| Drawer locking | Pedestal drawers include central locking for file security | |
| Modesty coverage | Full-height front panel blocks leg visibility from seated front view | |
| Surface work area | 1.8 sqm flat work surface supports monitor, documents, and task items | |
| Suite modularity | Coordinates with matching tall storage credenza and wall bookcase | |
| Assembly configuration | Knock-down panel assembly with metal connector hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Designed for single-user senior management workspaces with full suite storage | |
|---|---|---|
| Corporate headquarters office | Durable commercial construction suitable for high-use professional environments | |
| Small business owner office | Scaled 2m footprint fits standard private office room dimensions | |
| Formal meeting/negotiation office | Polished two-tone finish presents professional appearance for guest interactions | |
| Open-plan management workstation | Closed panel base provides privacy and noise reduction in open office layouts | |
| Co-working private office suite | Modular storage compatibility supports flexible premium workspace configuration |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial use validation | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and performance requirements, applicable for ergonomic checks | |
| EN 13722:2004 | Office furniture storage units strength and durability, applicable for matching pedestal validation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability, and structural performance acceptance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural integrity verification | |
|---|---|---|
| GB/T 3327-2023 | Office furniture desks, applicable for dimensional and performance acceptance testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for material safety verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrity verification; 2. GB/T 3327-2023: Office furniture desks, applicable for dimensional and performance acceptance testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for material safety verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
