| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimension (main desk x return) | 1800 x 1600 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 120 kg | |
|---|---|---|
| Storage shelf static load per tier | 25 kg | |
| Product net weight | 85 kg | |
| Recommended user count | 1 person | |
| Modesty panel impact resistance | 30 kg | |
| Leveling foot load per leg | 80 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | Wood grain melamine laminate, 25mm thick particleboard core | |
|---|---|---|
| Support frame | Matte black powder-coated steel rectangular tubing | |
| Modesty panel | Matte black steel sheet, 1.2mm thick | |
| Storage cabinet body | Black melamine laminate particleboard, 18mm thick | |
| Shelf panels | Black melamine laminate particleboard, 18mm thick | |
| Leveling feet | Nylon base with galvanized steel threaded stem | |
| Modesty panel brackets | Chrome-plated steel vertical support rods | |
| Edge banding | Matching PVC edge trim, 2mm thick | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated side storage | Two-tier open shelf unit on left return for books and office supplies | |
|---|---|---|
| Cable management routing | Rear under-desk channel for power and data cables | |
| Floor leveling adjustment | Threaded adjustable feet on all legs to compensate for uneven floors | |
| Front modesty panel | Full-width steel privacy panel to block leg visibility from front | |
| L-shaped work surface | Extended return worktop for additional task space or peripheral placement | |
| Weight distribution design | Three-point support (cabinet, front leg, rear leg) for stable worktop | |
| Scratch-resistant work surface | Melamine finish resists scuffs from office equipment and writing tools | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for individual manager offices with integrated storage for documents | |
|---|---|---|
| Open-plan management workstation | Usable as designated senior staff desk in open office layouts | |
| Small business private office | Appropriate for startup or SME offices requiring compact L-shaped work area | |
| Home office executive setup | Suitable for dedicated home workspaces needing professional office functionality | |
| Reception manager workstation | Usable as front office manager desk with storage for visitor supplies | |
| Conference room side work desk | Suitable as auxiliary work surface in meeting rooms for presentation materials |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
