Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2200 x 1800 x 750 mm | |
|---|---|---|
| Main work surface depth | 900 mm | |
| Left return width | 1200 mm | |
| Desktop thickness | 50 mm | |
| Edge banding thickness | 3 mm | |
| Knee clearance width | 800 mm | |
| Knee clearance height | 650 mm | |
| Base plinth height | 50 mm | |
| Cable grommet diameter | 80 mm | |
| Side panel thickness | 25 mm | |
| Return work surface depth | 600 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide static load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 100000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 185 kg | |
| Seating capacity | 1 person | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | High-density MDF core with walnut grain laminate | |
|---|---|---|
| Desktop finish | Scratch-resistant matte laminate coating | |
| Side and base panels | E1 grade particle board with dark taupe matte paint | |
| Edge banding | Matching PVC edge trim on all exposed panel edges | |
| Internal drawer construction | 18mm MFC (melamine faced chipboard) | |
| Drawer slides | Full extension cold-rolled steel ball bearing slides | |
| Door hinges | Soft-close steel cabinet hinges | |
| Cable management components | ABS plastic grommets with brush inserts | |
| Base plinth | Powder-coated steel kick plate with adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Work surface configuration | L-shaped layout with left return for extended work space | |
|---|---|---|
| Storage configuration | Enclosed pedestal drawers within solid box base with soft-close mechanism | |
| Cable management | Dual desk-top grommets with under-detachable cable tray | |
| Surface access | Central knee opening sized for ergonomic seated executive chair use | |
| Leveling adjustment | Adjustable base glides to compensate for uneven office flooring | |
| Drawer locking | Central lock system securing all pedestal drawers for document security | |
| Modesty panel | Full-height solid modesty panel integrated into box base front | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Sized for CEO, director or senior manager private office spaces | |
|---|---|---|
| Corporate headquarters | Appropriate for high-rise office tower executive suites with city views | |
| Home executive office | Suitable for upscale dedicated home office workspaces with formal design | |
| Meeting side use | Left return provides space for small 2-person side discussions across the desk |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and ergonomic requirements | |
| EN 13986:2004 | Wood-based panels for construction and furniture use, performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate | |
| GB/T 4897.3-2015 | Particle board specification for furniture use, applicable to base panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate; 3. GB/T 4897.3-2015: Particle board specification for furniture use, applicable to base panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
