Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main top + return credenza) | 2400mm W x 1800mm D x 750mm H | |
|---|---|---|
| Main desktop work surface thickness | 50mm | |
| Main desktop usable depth | 900mm | |
| Knee clearance under main work surface | 650mm W x 620mm H | |
| Left-side credenza dimensions | 1800mm W x 500mm D x 650mm H | |
| Modesty panel dimensions | 1200mm W x 350mm H x 20mm thick | |
| Desk top overhang beyond support structure | 80mm | |
| Angled metal support leg footprint | 70mm W, contact pad 80mm x 80mm | |
| Ventilation slot dimensions on credenza side panel | 80mm L x 8mm W, 5 evenly spaced slots | |
| Credenza base plinth height | 50mm | |
| Main desktop usable work depth | 900mm | |
| Left-side storage credenza external dimensions | 1800mm W x 500mm D x 650mm H | |
| Suspended front modesty panel dimensions | 1200mm W x 350mm H x 20mm thick | |
| Desktop overhang beyond front support structure | 80mm | |
| Right angled steel support leg footprint | 70mm profile width, floor contact pad 80mm x 80mm | |
| Credenza side ventilation slot dimensions | 80mm L x 8mm W, 5 evenly spaced horizontal slots |
Net weight / load capacity / users / durability
| Total product net weight range | 195kg | |
|---|---|---|
| Main desktop static load capacity | 120kg evenly distributed | |
| Recommended maximum user weight for desk use | 150kg | |
| Surface horizontal deflection under full load | <3mm at 120kg total top load | |
| Product usable lifespan | 10 years with standard office use | |
| Seating capacity at work surface | 1 primary user + 1 guest on return surface | |
| Surface horizontal deflection at full rated load | <3mm at 120kg total main top load | |
| Product usable service lifespan | Minimum 10 years under standard 8-hour daily office use | |
| Drawer slide static load rating (per drawer) | 25kg for stationery drawers, 45kg for file drawers | |
| Drawer and hinge cycle durability | 50,000 open/close cycles for slides, 80,000 open/close cycles for hinges |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25mm thick E0-grade high-density particleboard core | |
|---|---|---|
| Desktop surface finish | Smoked walnut wood veneer, 0.6mm thickness, matte anti-scratch polyurethane coating | |
| Credenza cabinet panels | 18mm thick E0-grade engineered wood, matching walnut veneer finish on visible faces | |
| Structural support frame | 2mm thick powder-coated dark gray steel rectangular tubing | |
| Right support leg assembly | 3mm thick powder-coated dark gray steel, angled geometric bracing design | |
| Front modesty panel | 20mm thick matte dark gray laminated MDF, suspended from desk frame | |
| Credenza ventilation slots | Integral cutouts in side wood panel, edge-banded to match finish | |
| Adjustable leveling feet | Nylon base with 10mm threaded steel stem, installed on credenza base plinth | |
| Drawer/door hardware (internal credenza) | Cold-rolled steel drawer slides with soft-close mechanism, 35mm cup hinges for doors | |
| Desk edge banding | 2mm thick matching PVC edge banding, radius 2mm | |
| Desktop edge treatment | 2mm thick matching walnut-grain PVC edge banding, 2mm rounded radius, hot-melt applied | |
| Internal credenza hardware | Cold-rolled steel full-extension drawer slides with soft-close mechanism, 35mm cup nickel-plated steel soft-close hinges for cabinet doors |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left credenza includes 2 file drawers for A4/legal documents, 2 stationery drawers, and 1 closed storage compartment for PC tower with side ventilation slots | |
|---|---|---|
| Cable management | Desktop integrated 2-port cable grommet with brush seal, under-desk cable tray routed from grommet to credenza PC compartment | |
| Soft-close hardware | All credenza drawers and doors have 100mm soft-close travel, no slam closure at final 50mm of travel | |
| Leveling adjustment | Credenza and desk leg feet have 15mm vertical adjustment range to compensate for uneven floor surfaces | |
| Work surface zoning | Main top provides primary monitor/laptop work zone, credenza top provides secondary meeting/document/guest work zone | |
| Modesty panel coverage | Suspended front modesty panel fully covers seated user leg area from front view, no gap between panel and desk top | |
| PC compartment ventilation | Side ventilation slots allow passive airflow for tower PC stored inside credenza, preventing overheating during continuous operation | |
| Load bearing structure | Angled steel right leg and credenza form dual support points, eliminating mid-desk sag under full load | |
| Cable management system | Desktop integrated 80mm diameter 2-port brush-seal cable grommet, paired with 150mm wide under-desk perforated steel cable tray routed from grommet to credenza PC compartment, 10kg maximum cable tray load capacity | |
| Soft-close hardware operation | All credenza drawers and doors have 100mm soft-close travel, engaging damping mechanism at final 50mm of closure to eliminate slamming and reduce wear | |
| Leveling adjustment range | Credenza and desk leg leveling feet provide 15mm total vertical adjustment range to compensate for uneven floor surfaces, with tool-free adjustment for installation | |
| Structural load distribution | Angled steel X-brace right leg and full-height credenza cabinet form dual rigid support points spaced 1400mm apart, eliminating mid-desk sag under full rated static load |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 cartons total (desktop, credenza cabinet, steel leg/frame, hardware kit) | |
|---|---|---|
| Largest carton dimensions (desktop) | 2450mm L x 950mm W x 120mm H | |
| Total shipping gross weight | 225kg | |
| Total shipping volume (CBM) | 0.68 CBM | |
| Indicative 20ft GP container loading quantity | 48 units | |
| Indicative 40ft HQ container loading quantity | 118 units | |
| On-site assembly time | 90minutes for 2 trained installers | |
| Largest carton dimensions (desktop panel) | 2450mm L x 950mm W x 120mm H | |
| Total shipping volume | 0.68 CBM | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Executive private office | Primary use case for director/manager offices in corporate, government, or financial workplace environments, providing professional appearance and full work/storage functionality | |
|---|---|---|
| Senior manager home office | Suitable for high-end home office setup for remote executives, combining work surface and integrated storage to reduce separate furniture needs | |
| Small meeting + individual work zone | Return credenza surface supports 2guest seats for quick 1-on-1 meetings without separate meeting table | |
| Workstations requiring integrated PC storage | Ventilated credenza compartment stores desktop PC tower out of sight, reducing desk clutter while maintaining equipment cooling | |
| Modern contemporary office interiors | Matches dark wood + matte metal design palettes for minimalist, high-end commercial interior fit-outs | |
| Recommended matching furniture | Pair with high-back ergonomic executive chair, 2 visitor side chairs, and mobile under-desk pedestal for expanded storage | |
| Adjacent 1-on-1 meeting space | Return credenza work surface accommodates 1 guest seat for quick informal meetings, document signings, or collaborative review without requiring a separate meeting table | |
| Workspaces requiring enclosed PC storage | Ventilated credenza compartment stores full-size desktop PC tower out of sight to reduce desk clutter, while side slots maintain passive airflow to prevent equipment overheating |
European market access and chemical requirements
| EN 527-1:2011+A1:2015 | Office furniture - Work tables and desks: Part 1 Dimensions: applicable for ergonomic dimension verification including work surface height and knee clearance | |
|---|---|---|
| EN 527-2:2016+A1:2019 | Office furniture - Work tables and desks: Part 2 Safety, strength and durability: applicable for structural stability, load, and fatigue test acceptance | |
| EN 13722:2004 | Office furniture - Storage units: applicable for credenza cabinet strength, drawer load, and durability acceptance |
US and Canada office-furniture standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture: applicable for dimensional tolerance, surface quality, and structural strength acceptance of this desk | |
|---|---|---|
| GB/T 3327-2017 | Office desks and tables: applicable for desktop load, stability, and leg strength performance acceptance | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: required E0 emission level (<0.05mg/m³) for all wood components for indoor office use | |
| GB/T 4893.8-2013 | Test for surface resistance to abrasion: applicable for desktop finish durability acceptance, minimum 2000 abrasion cycles without finish penetration |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture: applicable for dimensional tolerance, surface quality, and structural strength acceptance of this desk; 2. GB/T 3327-2017: Office desks and tables: applicable for desktop load, stability, and leg strength performance acceptance; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: required E0 emission level (<0.05mg/m³) for all wood components for indoor office use; 4. GB/T 4893.8-2013: Test for surface resistance to abrasion: applicable for desktop finish durability acceptance, minimum 2000 abrasion cycles without finish penetration; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
