Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + side return) | 2400 x 1800 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk unit net weight | 115 kg | |
|---|---|---|
| Main work surface static load capacity | 120 kg | |
| Recommended maximum user weight for seated use | 120 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Product service life reference | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 25mm E1 grade particleboard with walnut woodgrain melamine laminate | |
|---|---|---|
| Modesty panel and cabinet body | 18mm E1 grade particleboard with matte off-white melamine finish | |
| Support legs | Powder-coated matte off-white steel tubing with angled geometric design | |
| Edge banding | 2mm thick impact-resistant ABS matching panel colors, applied to all exposed edges | |
| Cabinet adjustment feet | Injection-molded nylon height-adjustable feet with 10mm adjustment range | |
| Cable management box | Injection-molded ABS cover with integrated brush strips for cable pass-through | |
| Side cabinet ventilation grilles | Laser-cut horizontal slits on cabinet side panel for equipment heat dissipation | |
| Panel connecting hardware | Zinc-plated steel cam lock fasteners for rigid panel joint assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| L-shaped dual work zone layout | Provides separate main writing/typing zone and auxiliary document/meeting zone | |
|---|---|---|
| Integrated central cable management | Recessed desk-top access box routes power and data cables below work surface | |
| Fixed side storage cabinet | Provides enclosed under-desk storage for CPUs, documents and office supplies | |
| Full-width modesty panel | Conceals under-desk leg area and wiring for front-facing office privacy | |
| Height-adjustable cabinet feet | Compensates for uneven carpeted or hard flooring to keep work surface level | |
| Ventilated equipment storage compartment | Side panel slits allow air circulation for CPUs or network equipment stored in cabinet | |
| Knockdown assembly design | Ships flat-packed for reduced freight cost, assembled with standard hex key hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private offices | Suits senior management workspaces requiring separate work and meeting surface areas | |
|---|---|---|
| Mid-size open-plan manager workstations | Provides sufficient work surface without occupying excessive open office floor space | |
| Small conference meeting spaces | L-shaped surface supports small 3person discussions alongside individual work | |
| Commercial office fit-out projects | Standard commercial sizing and panel construction aligns with bulk procurement specifications | |
| Home executive workspaces | Provides dedicated professional work area with integrated storage for home office setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables dimensional and safety requirements, applicable to work surface height and clearance | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables mechanical stability and strength requirements, applicable to load ratings |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for vertical and horizontal load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction quality | |
|---|---|---|
| GB/T 3327-2016 | Office desk dimensional and stability performance requirements, applicable to load and sizing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to particleboard material safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction quality; 2. GB/T 3327-2016: Office desk dimensional and stability performance requirements, applicable to load and sizing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to particleboard material safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
