Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Net product weight | 62 kg | |
| Recommended user capacity | 1 person | |
| Leveler maximum height adjustment | 10 mm | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | Light gray woodgrain high-pressure laminate over MDF core | |
|---|---|---|
| Desk legs | Dark blue powder-coated cylindrical steel tubes with brass accent rings | |
| Modesty panel | Dark blue powder-coated 1.2mm thick steel sheet with integrated cable management slots | |
| Mobile pedestal cabinet | Dark blue laminate over particleboard body with steel drawer runners | |
| Cable grommet | Black ABS plastic two-piece hinged cover with cable pass-through slots | |
| Leveler feet | Black nylon threaded feet with steel insert mounted to leg base | |
| Pedestal casters | Black nylon swivel casters without brake for easy repositioning | |
| Frame connection hardware | Zinc-plated steel bolts and corner brackets for rigid structural assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Desktop cable management | Embedded rectangular grommet routes power and data cables from work surface to under-desk space | |
|---|---|---|
| Under-desk cable routing | Horizontal slots along modesty panel top edge guide cables along worktop underside | |
| Mobile pedestal storage | Rolling pedestal fits under left desk section for lockable document and office supply storage | |
| Floor leveling adjustment | Threaded feet on all desk legs rotate to adjust height and eliminate wobble on uneven floors | |
| Front privacy screening | Full-height steel modesty panel blocks seated leg view from front of desk | |
| Pedestal mobility | Four swivel casters on pedestal base allow unit to be repositioned to left or right of desk | |
| Height adaptation | Fixed 750mm worktop height aligns with standard ergonomic seated office posture | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Fits single-user management workspaces with integrated storage and clean cable layout | |
|---|---|---|
| Open-plan supervisor workstation | Provides dedicated work surface and side storage for team leads in open office layouts | |
| Small meeting room workspace | Serves as a compact writing and presentation surface in small 3person meeting rooms | |
| Home office premium setup | Suitable for dedicated home workspaces requiring formal office aesthetics and storage | |
| Corporate staff workstation | Complies with standard commercial office specifications for administrative and professional staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktable safety requirement applicable to structural stability and edge radius compliance | |
|---|---|---|
| EN 527-2:2016 | Office worktable dimension requirement applicable to work surface height and clearance verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard applicable to static load, durability and stability testing for commercial use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirement applicable to wooden office furniture flat surface strength and dimensional tolerance | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture structural strength requirement applicable to steel leg and frame load testing | |
| GB/T 3327-2023 | Office desk performance test method applicable to static load and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirement applicable to wooden office furniture flat surface strength and dimensional tolerance; 2. GB/T 3325-2017: Metal furniture structural strength requirement applicable to steel leg and frame load testing; 3. GB/T 3327-2023: Office desk performance test method applicable to static load and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
