| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (main desk + side return) | 2400 x 2000 x 760 mm | |
|---|---|---|
| Main work surface depth | 900 mm | |
| Side return surface width | 1200 mm | |
| Desktop panel thickness | 50 mm | |
| Seated knee clearance height under main work surface | 650 mm | |
| Knee opening width (left fixed support to side pedestal) | 1600 mm | |
| Side storage pedestal depth (front to back) | 600 mm | |
| Side storage pedestal height | 720 mm | |
| Left end panel thickness | 50 mm | |
| Vertical slat modesty panel width | 200 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer interior depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Total product net weight range | 185 kg | |
| Recommended user capacity | 1 person | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 10 N·m | |
| Drawer slide static load rating | 40 kg | |
| Drawer slide cycle life | 50000 cycles | |
| Hinge cycle life | 80000 cycles | |
| Finish stain resistance | 24 hours | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop work surface | E1-grade MDF core with dark wood grain matte laminate top and solid color matte edge banding | |
|---|---|---|
| Front modesty panel (main section) | E1-grade MDF core with matte gray paint finish | |
| Vertical ribbed decorative section (modesty panel left) | E1-grade MDF slats with matching gray matte finish | |
| Left end support panel | E1-grade MDF core with vertical dark wood grain veneer/laminate finish | |
| Right side storage pedestal outer panel | E1-grade MDF core with matte taupe paint finish and horizontal grooved decorative detailing | |
| Storage drawer interiors | E1-grade MDF with smooth melamine finish | |
| Drawer slides | Cold-rolled steel three-quarter extension ball bearing slides | |
| Desk base leveling feet | Nylon adjustable glides | |
| Desktop edge trim | 2mm thick PVC edge banding, color-matched to panel finishes | |
| Internal support frame | 1.2mm thick cold-rolled square steel tubing with powder coat finish | |
| Pedestal back panel | 8mm thick hardboard with matte black finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Integrated fixed right-side storage pedestal | Attached cabinet unit with 1 filing drawer and 1 utility drawer for document and office supply storage, fixed to desk frame without independent mobility | |
|---|---|---|
| Center desktop cable management access | Recessed flip-up cable grommet located at center of main work surface to route monitor and laptop power/data cables below desk surface | |
| Full-width solid modesty panel | Continuous front panel below main work surface that blocks view of seated user's legs for privacy, with decorative vertical slat accent on left segment | |
| Adjustable base leveling | Threaded nylon glides at all ground contact points adjust up to 15mm to level desk on uneven carpet or hard flooring | |
| Soft-close drawer mechanism | Drawers fitted with soft-close dampers to prevent slamming and reduce noise during office use | |
| Filing drawer compatibility | Lower pedestal drawer sized to accommodate letter and A4 size hanging file folders with integrated metal file rails | |
| L-shaped dual work zone layout | Primary work surface faces front for core computer work, side return surface provides additional space for meetings, paperwork or peripheral equipment | |
| Under-desk cable routing channel | Integrated 60mm wide plastic cable channel mounted below desktop to route cables from grommet to wall outlets, preventing cable tangling | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 | |
|---|---|---|
| Largest shipping carton dimensions | 2450 x 950 x 120 mm | |
| Total shipping gross weight | 210 kg | |
| Total shipping volume (CBM) | 0.62 | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading quantity | 26 units | |
| 40ft HQ container loading quantity | 68 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Private executive office | Designed for dedicated manager, director or C-suite private offices, providing generous work surface and integrated storage to support individual focused work | |
|---|---|---|
| Corporate meeting and consultation space | Suitable for small in-office meetings with 2visitors across the desk, with extended side surface to hold meeting materials and presentation devices | |
| Professional services partner offices | Ideal for law firm, accounting firm or consultancy partner offices where client-facing aesthetics and document storage capacity are required | |
| Commercial office open plan manager stations | Can be deployed in open plan office areas as a designated team manager workstation, with integrated storage eliminating need for separate filing cabinets | |
| Recommended matching configurations | Pair with high-back executive leather office chair, desktop monitor arm and under-desk cable management tray for complete ergonomic work setup | |
| Government/enterprise leadership offices | Suitable for formal government or state-owned enterprise leadership offices, meeting requirements for durable construction and professional, understated aesthetics |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Worktables and desks - Part 1: Dimensions, applicable for ergonomic work surface height and clearance verification | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office furniture - Worktables and desks - Part 2: Mechanical safety requirements and test methods, applicable for structural safety and stability acceptance | |
| EN 13986:2004+A1:2015 | Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking, applicable for panel material performance verification | |
| EN 15372:2008 | Furniture - Durability assessment for office furniture - Strength, durability and stability requirements for work surfaces and storage units, applicable for long-term performance acceptance |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural strength, dimensional tolerance and finish quality acceptance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable for desk stability, load capacity and ergonomic dimension acceptance for commercial office use | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels, applicable for E1-grade panel formaldehyde emission acceptance | |
| GB/T 4897.3-2003 | Particleboard - Part 3: Requirements for furniture use, applicable for core panel material performance verification if particleboard is used |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural strength, dimensional tolerance and finish quality acceptance; 2. GB/T 3327-2016: Office desks and tables, applicable for desk stability, load capacity and ergonomic dimension acceptance for commercial office use; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels, applicable for E1-grade panel formaldehyde emission acceptance; 4. GB/T 4897.3-2003: Particleboard - Part 3: Requirements for furniture use, applicable for core panel material performance verification if particleboard is used; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
