Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 1800 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk net weight | 95 kg | |
|---|---|---|
| Worktop static load capacity | 120 kg | |
| Pedestal cabinet drawer static load | 25 kg | |
| Recommended user capacity | 1 person | |
| Leveling adjustment load per foot | 80 kg | |
| Surface abrasion resistance cycles | 2000 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop | 25mm thick E1 grade particleboard with matte white melamine laminate | |
|---|---|---|
| Pedestal cabinet carcass | 18mm thick E1 grade particleboard with white melamine finish | |
| Pedestal ventilation panel | 18mm thick particleboard with horizontal ventilation slots | |
| Support frame and legs | 1.5mm thick powder-coated matte silver square steel tubing | |
| Modesty panel | 18mm thick particleboard with matching white melamine finish | |
| Adjustable feet | Nylon base with steel threaded stem | |
| Cable grommet | ABS plastic black rectangular cable pass-through | |
| Drawer slides (if fitted) | Cold-rolled steel three-quarter extension ball bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommet | Rectangular top cutout routes power, network and peripheral cables below work surface | |
|---|---|---|
| Cantilever leg support | Open C-frame steel legs eliminate cross braces for unobstructed leg movement | |
| Left side storage pedestal | Enclosed cabinet supports the desk return and provides concealed file and supply storage | |
| Pedestal side ventilation | Horizontal slotted vents on cabinet end panel allow air flow for stored IT equipment | |
| Floor leveling adjustment | Threaded adjustable feet on pedestal and legs correct floor unevenness up to 10mm | |
| Front modesty panel | Fixed panel under worktop provides seated privacy and conceals under-desk cabling | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Largest shipping carton dimensions | 2050 x 850 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Provides dedicated spacious work surface and enclosed storage for management staff | |
|---|---|---|
| Open-plan manager workstation | Combines work area and return space for meeting with up to 2 visitors across the desk | |
| Home office workspace | Offers professional layout with integrated cable management for remote senior roles | |
| Small business reception workspace | Supports front desk administration and document storage in compact office layouts |
EU Market Access Requirements* EN Standards
| Office desk safety requirements | EN 527:2011 | |
|---|---|---|
| Desk dimensional ergonomics | EN 527:2002 | |
| Formaldehyde emission for panels | EN 13986:2004 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Desk dimensional tolerance | GB/T 3326 | |
|---|---|---|
| Panel formaldehyde emission | GB 18580 | |
| Surface coating adhesion | GB/T 4893.4 | |
| Structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Desk dimensional tolerance: GB/T 3326; 2. Panel formaldehyde emission: GB 18580; 3. Surface coating adhesion: GB/T 4893.4; 4. Structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
