Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main work surface thickness | 60 mm | |
| Main worktop depth | 900 mm | |
| Left return credenza depth | 600 mm | |
| Seated knee clearance height under main top | 650 mm | |
| Seated knee clearance width at front opening | 1400 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Gold accent trim line thickness | 3 mm | |
| Return credenza surface height | 720 mm | |
| Return credenza internal storage shelf height | 320 mm | |
| File drawer internal usable dimensions | 440 x 340 x 300 mm | |
| Edge banding thickness on work surfaces | 2 mm | |
| Modesty panel thickness | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Assembled product weight | 240 kg | |
|---|---|---|
| Main worktop distributed static load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet door hinge cycle rating | 100000 open/close cycles | |
| Recommended maximum user weight rating for seated use | 150 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop core and finish | E1-grade MDF core with light oak melamine laminate | |
|---|---|---|
| Cabinet body construction | 18 mm thick E1-grade particleboard with charcoal matte melamine finish | |
| Decorative accent trim | Gold-tone plated metal inlay | |
| Edge banding | 2 mm thick matching PVC edge banding | |
| Storage hardware | Cold-rolled steel drawer slides, nickel-plated cabinet hinges | |
| Base feet | High-impact ABS plastic block feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left return credenza with enclosed cabinet, two utility drawers and one file drawer | |
|---|---|---|
| Cable management | Dual desktop grommets with under-detachable cable tray | |
| Privacy feature | Full-height front modesty panel | |
| Self-closing hardware | Soft-close drawer slides and door hinges |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Private executive and CEO offices | |
|---|---|---|
| Recommended supporting furniture | High-back executive office chair, 3-seat visitor seating set |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, applicable to safety, strength and stability requirements | |
|---|---|---|
| EN 12521:2015 | Furniture for non-domestic seating, links to desk ergonomic clearance dimensions | |
| EN 312:2010 | Particleboard performance specifications, applicable to cabinet body panel structural requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to static load, cycle and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to drawer, shelf and door performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish performance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable to dimension, stability and load requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, requires E1 grade ≤0.124 mg/m³ |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish performance; 2. GB/T 3327-2016: Office desks and tables, applicable to dimension, stability and load requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, requires E1 grade ≤0.124 mg/m³; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
