Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 1800 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Main desktop usable depth | 900 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance width | 1200 mm | |
| Right fixed storage cabinet width | 500 mm | |
| Side return depth | 600 mm | |
| Cable grommet size | 300 x 80 mm | |
| Storage cabinet kick height | 50 mm | |
| Modesty panel height | 450 mm | |
| Desktop corner radius | 50 mm | |
| Left support panel thickness | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight range | 145 kg | |
|---|---|---|
| Desktop uniform static load | 150 kg | |
| Drawer static load per unit | 25 kg | |
| Recommended maximum user weight | 130 kg | |
| Open shelf static load | 30 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 10 J | |
| Warranty period | 5 years | |
| Available color options | 3 | |
| Open storage shelf static load | 30 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main desktop | 25mm thick E0 grade particleboard core, walnut wood grain melamine finish, 2mm PVC edge banding | |
|---|---|---|
| Left structural support | 1.2mm thick cold-rolled steel, matte taupe powder coated finish | |
| Front modesty panel | MDF substrate, taupe base finish with printed grey scale-pattern decorative film | |
| Right storage cabinet outer panels | MDF substrate, taupe tech-leather upholstery with white contrast stitching at top and bottom edges | |
| Side return cabinet outer panels | 18mm thick E0 grade particleboard, matte taupe melamine finish, equipped with keyed cam lock | |
| Drawer internal components | 15mm thick MDF drawer sides, steel ball-bearing drawer slides | |
| Cable grommet | ABS plastic with brushed silver finish, includes brush seal for cable pass-through | |
| Kick plinth | 1.0mm thick cold-rolled steel, matte taupe powder coated finish, with adjustable leveling feet | |
| Hardware components | Zinc alloy lock cores, steel connecting screws, plastic cable management clips | |
| Base kick plinth | 1.0mm thick cold-rolled steel, matte taupe powder coated finish, fitted with M10 adjustable leveling feet | |
| Modesty panel frame | 1.0mm thick cold-rolled steel, matte taupe powder coated finish, mechanically fastened to desktop and left support | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Desktop-mounted brush grommet routes power and data cables from work surface to under-desk cavity, conceals excess cabling for neat workstation setup | |
|---|---|---|
| Lockable storage | Side return pedestal includes key-operated lock that secures all drawers and cabinet compartments to secure confidential documents | |
| Dual work surface layout | L-shaped configuration provides primary front work zone for daily computer work and secondary side return zone for printer, documents or visitor discussion | |
| Modesty coverage | Full-height front modesty panel blocks view of under-desk area and seated user legs from front office approach | |
| Storage configuration | Right fixed unit combines open storage shelf and closed upholstered-front cabinet, side return unit includes 2 lockable drawers and 1 file compartment for A4/FC document storage | |
| Floor leveling | Adjustable feet on base plinths compensate for uneven office floors, eliminating desk wobble on carpet or hard flooring | |
| Edge safety design | All desktop corners have large radius rounded edges to prevent impact injury during movement around the workstation | |
| Under-desk space compatibility | 620mm knee clearance supports standard height adjustable office chairs with seat height range 520 mm | |
| Mixed storage configuration | Right fixed unit combines 1 open storage shelf and closed upholstered-front cabinet, side return unit includes 2 lockable utility drawers and 1 file compartment for A4/FC document storage | |
| Under-desk seating compatibility | 620mm knee clearance supports standard executive office chairs with 520 mm seat height adjustment range, meets ergonomic seated work requirements | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of packages | 3 | |
|---|---|---|
| Main desktop carton dimensions | 2300 x 950 x 120 mm | |
| Storage cabinet carton dimensions | 1850 x 650 x 700 mm | |
| Total gross weight | 170 kg | |
| Total shipping volume (CBM) | 1.22 | |
| On-site assembly time | 90 minutes | |
| 40HQ container loading quantity | 72 units | |
| Interior packaging material | 50mm EPS foam corners, 5-layer corrugated carton, PE protective film for upholstered surfaces | |
| Total gross shipping weight | 170 kg | |
| Total shipping volume | 1.22 CBM |
Recommended spaces / users / usage modes
| Executive private office | Suitable for 30sqm independent manager/executive offices, provides professional appearance and sufficient storage for daily work documents and equipment | |
|---|---|---|
| Executive meeting room | Usable as a small conference desk for 4person internal discussions when paired with guest seating across the desktop | |
| High-end open office leadership zone | Appropriate for partitioned senior staff work areas in open plan offices, the decorative front panel provides visual privacy for the seated user | |
| Small business owner workspace | Suitable for home offices or private enterprise offices, integrated storage eliminates need for separate additional filing cabinets | |
| Recommended matching furniture | Pairs with high-back executive leather office chairs with 500 mm seat height, and 2 visitor side chairs for guest meetings | |
| Small internal meeting space | Usable as a small conference desk for 4-person internal discussions when paired with guest seating positioned across the desktop front | |
| Recommended matching furniture configuration | Pairs with high-back executive leather office chairs with 500mm standard seat height, and 2 armless visitor side chairs for guest meetings |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Applies to mechanical safety, strength and durability requirements for office work desks | |
|---|---|---|
| EN 13722:2004 | Applies to performance requirements for office storage pedestals and cabinets integrated with desks | |
| EN 14073-2:2004 | Applies to safety and strength requirements for office storage furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk dimension, strength and stability testing requirements for office work desks | |
|---|---|---|
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based furniture components used in indoor office environments | |
| GB/T 4897.3-2007 | Applies to performance requirements for particleboard used in furniture load-bearing structures | |
| GB/T 17657-2013 | Applies to surface abrasion and impact resistance testing for wood-based furniture panels |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk dimension, strength and stability testing requirements for office work desks; 2. GB 18584-2001: Applies to formaldehyde emission limits for wood-based furniture components used in indoor office environments; 3. GB/T 4897.3-2007: Applies to performance requirements for particleboard used in furniture load-bearing structures; 4. GB/T 17657-2013: Applies to surface abrasion and impact resistance testing for wood-based furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
