Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1800 x 1350 x 760 mm | |
|---|---|---|
| Main worktop thickness | 25 mm | |
| Return cabinet top thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Metal leg diameter | 60 mm | |
| Metal leg wall thickness | 1.2 mm | |
| Seated knee clearance height | 680 mm | |
| Seated knee clearance width | 1200 mm | |
| Seated knee clearance depth | 600 mm | |
| Drawer internal dimensions (per unit) | 450 x 380 x 150 mm | |
| Open cubby internal dimensions (per unit) | 350 x 380 x 300 mm | |
| Closed cabinet internal dimensions | 450 x 380 x 600 mm | |
| Adjustable foot height adjustment range | 10 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Product net weight | 60 kg | |
|---|---|---|
| Main worktop static load capacity | 100 kg | |
| Recommended user capacity | 1 person | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance rating | 2000 cycles | |
| Standard product warranty | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop panel | 25mm E1-grade particle board with grey wood-grain melamine laminate | |
|---|---|---|
| Storage cabinet carcass/frame | 18mm MDF with dark slate blue powder-coated laminate finish | |
| Drawer and cabinet door fronts | 18mm engineered wood with matching grey wood-grain laminate finish | |
| Support legs | 60mm diameter powder-coated dark blue cylindrical steel tubes with brass accent rings | |
| Leveler feet | Reinforced nylon with steel threaded stems for height adjustment | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges | |
| Drawer/cabinet hardware knobs | Matte black round ABS plastic knobs, 30mm diameter | |
| Modesty panel | 15mm dark blue engineered wood panel fixed under main worktop | |
| Cable grommets | ABS plastic wire management inserts with removable covers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 2 stacked drawers, 2 divided open cubbies, 1 closed cabinet door | |
|---|---|---|
| Drawer operation | Full-extension smooth-glide ball-bearing slides for full access to drawer contents | |
| Floor leveling | Threaded adjustable feet on all support points to compensate for uneven floors | |
| Cable management | Desktop cable grommets to route power and data cables from work surface to floor | |
| Cabinet shelf adjustability | 1-position adjustable shelf in closed cabinet to accommodate variable storage heights | |
| Work surface configuration | Continuous L-shaped layout with extended overhang over return cabinet for expanded work area | |
| Assembly requirement | Knock-down flat-pack assembly with included hardware and illustrated instructions | |
| Surface maintenance | Stain- and scratch-resistant melamine finish for easy cleaning with standard office cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Fits dedicated manager office spaces for daily paperwork and computer work | |
|---|---|---|
| Home office workspace | Suitable for large home offices requiring integrated storage without separate cabinets | |
| Small team open office | Works as a dedicated senior staff workstation in open-plan office layouts | |
| Conference side workstation | Can be used as a presentation prep station adjacent to meeting rooms | |
| Studio/co-working space | Provides durable work surface and storage for long-term co-working dedicated desks | |
| Recommended matching chair | Pairs with mid-back or high-back executive office chairs with 480 mm seat height | |
| Recommended accessory set | Pairs with monitor arm, desk mat and under-desk cable tray for optimized workspace |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for seated workstations | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional, safety and durability requirements for executive desks | |
| EN 13722:2004 | Furniture storage units strength and durability requirements for integrated cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, cycle and stability performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer, shelf and door durability performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for panel strength and dimensional tolerances | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required E1 emission grade for indoor use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for table stability and static load capacity |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for panel strength and dimensional tolerances; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required E1 emission grade for indoor use; 3. GB/T 10357.1-2013: Furniture mechanical performance test for table stability and static load capacity; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
