Automatic mm / inch conversion · Core engineering specifications
| overall footprint | 2000 x 1800 x 760 mm | |
|---|---|---|
| main worktop thickness | 38 mm | |
| return cabinet worktop thickness | 25 mm | |
| knee clearance height | 690 mm | |
| knee clearance width | 1200 mm | |
| main worktop depth | 800 mm | |
| return cabinet depth | 600 mm | |
| PVC edge band thickness | 2 mm | |
| steel T-leg wall thickness | 1.5 mm | |
| cable grommet diameter | 60 mm | |
| modesty panel height | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| main worktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| hinge cycle rating | 80000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| net weight | 76 kg | |
| user weight rating | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| main worktop | High-density particleboard core, light oak melamine laminate, 2mm PVC edge banding | |
|---|---|---|
| return cabinet body | E1-grade MFC board, matte white melamine finish, matching PVC edge sealing | |
| T-shaped support leg | Powder-coated matte white steel, floor glide feet for level adjustment | |
| front modesty panel | 18mm thick MDF panel, matte white melamine finish, fixed to worktop underside | |
| drawer hardware | Cold-rolled steel three-section full-extension slides, zinc-plated finish | |
| cabinet hinges | Soft-close steel hinges, nickel-plated finish, 110-degree opening angle | |
| cable management vents | ABS plastic vented grommets, matte white finish, mounted on return cabinet side | |
| surface finish | Scratch, stain and spill-resistant melamine laminate, low-sheen matte texture | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| fixed worktop height | 760 mm fixed seated work height, no height adjustment mechanism | |
|---|---|---|
| left-side storage return | Integrated fixed pedestal cabinet with lockable storage drawers and open cable routing | |
| cable management system | Desktop grommet pass-through, side vented cable port, under-desk routing channel for power and data cords | |
| floor levelling adjustment | Adjustable glide feet on T-leg base and cabinet base, 10 mm adjustment range for uneven floors | |
| drawer operation | Full-extension soft-close drawers, integrated locking mechanism for secure file storage | |
| work surface layout | L-shaped extended work area, provides separate zones for computer work and document review | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 2100 x 900 x 150 mm (worktop carton), 900 x 700 x 650 mm (hardware/cabinet carton) | |
|---|---|---|
| total shipping gross weight | 92 kg | |
| total shipping volume | 0.69 CBM | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Suitable for manager or director private workspaces, provides large work and storage surface | |
|---|---|---|
| open-plan manager workstation | Applicable for senior team lead work areas in open office layouts, integrated storage reduces clutter | |
| dual-monitor computer work | 800mm deep main worktop supports dual monitors, laptop and document layout without crowding | |
| small meeting workspace | Extended return surface provides space for 2visitors to review documents across the desk | |
| cable-enabled workspace | Integrated cable routing supports desktop PC, monitor, phone and charging device cord management |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial office desk performance | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables, dimension, surface and mechanical safety requirements | |
| EN 13722:2004 | Office furniture, storage cabinets, structural performance and durability testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products, standard for static load, durability and stability testing for office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units, performance and durability standard for attached cabinet pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk structural performance and finish quality | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable to dimension tolerances, stability and load testing requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade panel material compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk structural performance and finish quality; 2. GB/T 3327-2016: Office desks and tables, applicable to dimension tolerances, stability and load testing requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade panel material compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
