Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desk net weight | 125 kg | |
|---|---|---|
| Worktop static load capacity | 150 kg | |
| Recommended user capacity | 1 person | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm thick E1 grade particleboard with light oak melamine finish | |
|---|---|---|
| Storage cabinet body | 18mm thick E1 grade particleboard with dark green matte powder-coated finish | |
| Drawer fronts and panels | 18mm thick E1 grade particleboard matching dark green cabinet finish | |
| Desk support legs | 1.5mm thick rectangular powder-coated steel tube, dark green finish | |
| Desk underframe cross rails | 1.2mm thick powder-coated steel tube, dark green finish | |
| Drawer slides | Cold-rolled steel 3-section full-extension ball bearing slides | |
| Cabinet base plinth | 18mm thick particleboard matching dark green cabinet finish, raised 50mm off floor | |
| Edge banding | 2mm thick PVC edge matching panel finish on all exposed panel edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Left return storage | Full-length closed cabinet provides concealed file and office supply storage | |
|---|---|---|
| Under-worktop storage | Two suspended drawer units provide accessible under-desk storage for documents and supplies | |
| Cable management access | Recessed cable port at worktop-cabinet junction routes power and data cables off the work surface | |
| Stable work support | Steel frame with rigid cross-bracing prevents worktop deflection under full rated load | |
| Floor protection | Elevated plinth base prevents cabinet bottom contact with floor, reducing moisture and scratch risk | |
| Ergonomic seated access | Open knee bay accommodates standard height-adjustable office chairs with full leg extension | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Designed for individual manager use, providing sufficient work surface and integrated private storage | |
|---|---|---|
| Open-plan senior workstation | Suitable for team lead workstations in open offices, separating personal storage from shared work area | |
| Small conference side desk | Usable as a secondary work surface in small meeting rooms for document preparation and meeting materials storage | |
| Home office executive setup | Appropriate for dedicated home offices requiring professional storage and large work surface for computers and documents |
EU Market Access Requirements* EN Standards
| Office desk safety requirements | EN 527:2011 Office furniture - Work tables and desks - Part 1: Dimensions | |
|---|---|---|
| Formaldehyde emission for panel products | EN 13986:2004 Wood-based panels for construction - E1 class |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Desk panel formaldehyde emission | GB/T 18580E1 grade | |
|---|---|---|
| Office desk structural stability | GB/T 3324General technical requirements for wooden furniture | |
| Metal surface coating adhesion | GB/T 2020Paint film adhesion test grade 1 |
This product must meet the following technical requirements: 1. Desk panel formaldehyde emission: GB/T 18580E1 grade; 2. Office desk structural stability: GB/T 3324General technical requirements for wooden furniture; 3. Metal surface coating adhesion: GB/T 2020Paint film adhesion test grade 1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
