Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall L-shaped footprint | 1800 x 1600 x 760 mm | |
|---|---|---|
| Main work surface width | 1800 mm | |
| Main work surface depth | 800 mm | |
| Left return storage cabinet width | 1200 mm | |
| Left return storage cabinet depth | 600 mm | |
| Work surface thickness | 28 mm | |
| Seated knee clearance height | 680 mm | |
| Seated knee clearance width | 1200 mm | |
| Seated knee clearance depth | 550 mm | |
| Cable grommet dimensions | 80 x 160 mm | |
| Edge band thickness | 3 mm | |
| Support foot height | 30 mm | |
| Front modesty panel height | 600 mm | |
| Gold decorative trim width | 5 mm | |
| Desktop to floor height | 760 mm | |
| Return cabinet vent slot dimensions | 15 x 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 136 kg | |
|---|---|---|
| Return cabinet shelf static load | 45 kg | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Overall product net weight | 150 kg | |
| Cable grommet cable capacity | 12 cables | |
| Recommended user weight capacity | 136 kg | |
| Surface heat resistance | 120 °C | |
| Leveling adjustment range | 25 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main work surface | 28mm thick 45lb density particleboard core with dark gray thermofused laminate finish | |
|---|---|---|
| Cabinet panels and modesty panel | 18mm thick engineered wood with matte charcoal laminate finish | |
| Decorative accent trim | Gold-toned PVC or metallic inlay trim | |
| Structural support frame | 1.2mm thick powder-coated steel internal frame | |
| Edge banding | 3mm thick impact-resistant PVC edge banding | |
| Support feet | High-density polypropylene block feet with non-slip pads |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed rectangular desktop grommet routes power and data cables below work surface | |
|---|---|---|
| Storage functionality | Left return cabinet provides enclosed storage for CPU and office files, with side ventilation slots | |
| Privacy screening | Full front modesty panel blocks view of seated user's legs from front office approach | |
| Stability support | Low block base feet distribute weight evenly and prevent floor scuffing |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suitable for director or manager private offices, providing dedicated work surface and enclosed storage | |
|---|---|---|
| Senior management workspace | Fits professional corporate environments with formal dark gray and gold accent aesthetic |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to work surface height and clearance dimensions | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Part 2: Mechanical safety requirements and test methods | |
| EN 15372:2016 | Furniture - Strength, durability and safety for office storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for safety, durability, and structural performance of office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for safety, durability, and structural performance of office storage |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to desktop and cabinet core material quality | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and structural integrity; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to desktop and cabinet core material quality; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
