| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2450 x 1850 x 750 mm | |
|---|---|---|
| main worktop depth | 900 mm | |
| left return/credenza width | 1200 mm | |
| knee clearance height | 650 mm | |
| knee clearance width | 800 mm | |
| worktop thickness | 50 mm | |
| edge band thickness | 2 mm | |
| pedestal base panel thickness | 25 mm | |
| cable grommet diameter | 80 mm | |
| adjustable foot height adjustment | 15 mm | |
| drawer internal depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| static worktop load capacity | 150 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| recommended user weight | 150 kg | |
| product net weight | 130 kg | |
| standard warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop substrate | E0 grade MDF board | |
|---|---|---|
| worktop finish | Matte blue-gray polyurethane lacquer | |
| trim and accent panels | Dark gray wood grain veneer | |
| pedestal cabinet panels | 25mm melamine faced particleboard | |
| edge banding | 2mm PVC laser-sealed edge banding | |
| drawer slides | Cold-rolled steel soft-close full-extension slides | |
| cabinet hinges | Nickel-plated steel soft-close hinges | |
| leveling feet | Nylon base with steel threaded stem | |
| cable grommets | ABS plastic with brushed metal finish cap | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| left attached storage pedestal | Integrated cabinet with file drawers and closed storage | |
|---|---|---|
| integrated cable management | Dual desktop grommets with under-desk cable tray | |
| soft-close drawer operation | Self-closing slides with 45kg load rating | |
| lockable storage compartments | Centralized key lock for drawers and cabinet doors | |
| leveling adjustment | 15mm adjustable feet at all base corners | |
| modesty panel | Full-width solid front panel under main worktop | |
| seamless work surface | Flush joint between main top and return | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| executive private office | Suitable for CEO/manager private offices with matching storage units | |
|---|---|---|
| corporate headquarters | Ideal for high-grade corporate office fit-outs | |
| home executive office | Fits large home office spaces for remote senior professionals | |
| paired with high-back executive chair | Designed for use with ergonomic high-back executive seating | |
| configuration with matching bookcase | Coordinates with matching full-wall storage bookcase units | |
| seated single-user operation | Designed for one primary seated user facing office entry |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Desk Products performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances | |
| GB/T 10357.1-2013 | Test of mechanical properties of furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; 3. GB/T 10357.1-2013: Test of mechanical properties of furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
