Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1600 x 760 mm | |
|---|---|---|
| Main work surface depth | 800 mm | |
| Main work surface thickness | 50 mm | |
| Return cabinet dimensions | 1200 x 450 x 700 mm | |
| Knee clearance height under desk | 700 mm | |
| Knee clearance width between supports | 1200 mm | |
| Edge band thickness | 2 mm | |
| Steel frame tube wall thickness | 1.5 mm | |
| Cable grommet diameter | 80 mm | |
| CPU compartment internal dimensions | 250 x 430 x 500 mm | |
| Open shelf compartment internal dimensions | 400 x 400 x 250 mm | |
| Adjustable foot pad height adjustment | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 91 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Total product weight range | 64 kg | |
| Recommended maximum user weight load | 136 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Recommended warranty period | 12 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | 50mm E1-grade engineered wood with light gray matte laminate | |
|---|---|---|
| Support frame | White powder-coated square steel tube | |
| Storage cabinet panels | 18mm E1-grade engineered wood with matching light gray laminate | |
| Edge trim | 2mm PVC edge banding matching surface color | |
| Drawer hardware | Zinc-plated steel ball-bearing drawer slides | |
| Door and drawer lock | Zinc alloy keyed cam lock | |
| Cable grommet | ABS plastic wire management grommet | |
| Adjustable foot pads | Nylon base with steel threaded stem | |
| Frame connection hardware | Zinc-plated steel bolts and cam locks | |
| CPU compartment back panel | 3mm hardboard with ventilation cutouts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| L-shaped corner layout | Provides extended dual-zone work surface for multitasking and multiple monitors | |
|---|---|---|
| Lockable lower drawer | Secures confidential documents and valuables with included key lock | |
| Dedicated CPU compartment | Holds full-size desktop computer tower for off-floor storage | |
| Open upper shelf | Provides open storage for frequently accessed books and office supplies | |
| Closed cabinet compartment | Conceals stored items behind a fixed solid left-side panel | |
| Desktop cable grommet | Routes monitor and peripheral cables through work surface to floor | |
| Open cantilever frame | Creates unobstructed knee clearance without crossbars blocking leg movement | |
| Adjustable leveling feet | Stabilizes desk on uneven floors by adjusting individual foot height | |
| Scratch-resistant laminate surface | Resists daily wear from office equipment and writing tasks | |
| Lockable drawer internal dimensions | 400 x 400 x 150 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Provides generous work and storage space for manager and executive use | |
|---|---|---|
| Home office workspace | Suitable for dedicated home work areas requiring organized document and equipment storage | |
| Small business open office | Works as a standalone manager station in open plan office layouts | |
| Standard seated use | 760mm work height pairs with standard ergonomic office chairs | |
| Computer-focused workstations | Dedicated CPU compartment and cable management support desktop computer setups | |
| Document-heavy roles | Integrated storage supports roles requiring frequent access to files and office supplies | |
| Light gray modern interiors | Neutral light gray and white finish coordinates with contemporary office design schemes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and stability requirements for office use | |
| EN 13722:2004 | Furniture strength and durability test methods for storage components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel quality and structural stability | |
|---|---|---|
| GB/T 3327-2018 | Performance test methods for office desks, applicable to load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood panels, required for indoor office furniture | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel quality and structural stability; 2. GB/T 3327-2018: Performance test methods for office desks, applicable to load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood panels, required for indoor office furniture; 4. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
