Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1800 × 760 mm | |
|---|---|---|
| Overall assembled dimensions | 2400 x 1800 x 760 mm | |
| Main worktop thickness | 25 mm | |
| ABS edge banding thickness | 2 mm | |
| Storage pedestal/return top thickness | 25 mm | |
| Modesty/side support panel thickness | 18 mm | |
| Central seated knee clearance height | 650 mm | |
| Central knee clearance width | 800 mm | |
| Knee clearance depth under worktop | 600 mm | |
| Left storage return depth | 600 mm | |
| Integrated cable grommet diameter | 80 mm | |
| Open-loop steel support leg wall thickness | 2 mm | |
| Floor leveler adjustment height | 15 mm | |
| Worktop overhang past front support | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide rated load per drawer | 35 kg | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Cabinet door hinge cycle durability | 80000 open/close cycles | |
| Recommended maximum user weight for seated use | 150 kg | |
| Melamine finish abrasion resistance | 2000 cycles | |
| Recommended number of users | 1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main worktop substrate | High-density particleboard | |
|---|---|---|
| Worktop surface finish | Matte light oak melamine laminate | |
| Storage pedestal/return substrate | High-density particleboard | |
| Pedestal surface finish | Matte light off-white powder paint | |
| Right open-loop support frame | Powder-coated mild steel | |
| Edge banding | 2mm ABS plastic | |
| Storage drawer slides | Cold-rolled steel ball-bearing slides | |
| Cabinet door hinges | Cold-rolled steel concealed hinges | |
| Cable grommet | ABS plastic with brushed cap | |
| Floor levelers | Nylon base with steel threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed left-side storage return | Integrated non-reversible cabinet unit with enclosed storage compartments | |
|---|---|---|
| Integrated cable management port | Top-access grommet routes power and data cords from work surface to under-desk area | |
| Cantilever open-leg support | Sculpted closed-loop steel leg provides unobstructed legroom on the right seating side | |
| Adjustable floor levelers | Threaded feet compensate for uneven flooring to keep worktop perfectly level | |
| Enclosed pedestal storage | Cabinet compartments accommodate hanging files, office supplies and CPU tower | |
| Rounded worktop edges | Bullnose rounded front and side edges reduce impact injury risk | |
| Fixed worktop height | 760 mm standard ergonomic working height for seated office tasks | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Primary use for CEO, director or senior manager dedicated workspaces | |
|---|---|---|
| Manager-level open office | Suitable for team supervisor workstations requiring integrated storage | |
| High-end home office | Appropriate for luxury residential workspaces with modern interior design | |
| Corporate boardroom auxiliary space | Can be used as a boardroom side work surface or meeting prep station | |
| Professional consulting office | Suitable for legal, finance or consulting client meeting workspaces | |
| Pairing recommendation | Matches light leather executive chairs and matching back wall storage bookcases |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance validation | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability, applicable to pedestal cabinet | |
| EN 717-1:2004 | Wood-based panel formaldehyde emission testing, required for indoor air quality compliance |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products safety and performance standard, applicable to load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Office storage units performance standard, applicable to pedestal cabinet testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture air quality | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable to worktop and pedestal substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture air quality; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable to worktop and pedestal substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
