Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (L x W x H) | 1830 x 1830 x 760 mm | |
|---|---|---|
| Main work surface depth | 850 mm | |
| Side return work surface depth | 400 mm | |
| Worktop thickness | 41 mm | |
| PVC edge band thickness | 3 mm | |
| Knee clearance height under main desk | 690 mm | |
| Knee clearance width (central leg opening) | 1100 mm | |
| Steel leg outer diameter | 50 mm | |
| Steel leg wall thickness | 1.5 mm | |
| Perforated modesty panel dimensions | 1200 x 400 mm | |
| Embedded cable grommet diameter | 80 mm | |
| Storage cabinet internal shelf clearance | 320 mm | |
| Adjustable foot glide height adjustment | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Whole desk net weight | 68 kg | |
|---|---|---|
| Main worktop static uniform load capacity | 68 kg | |
| Storage drawer slide dynamic load rating | 25 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Door hinge open/close cycle durability | 80000 cycles | |
| Recommended maximum user weight for seated use | 136 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main work surface | E1 grade melamine-faced engineered wood | |
|---|---|---|
| Side return work surface | Matching E1 grade melamine-faced engineered wood | |
| Storage cabinet body | Dark grey melamine-faced engineered wood | |
| Desk support legs | Powder-coated dark grey tapered steel | |
| Modesty panel | Perforated dark grey powder-coated steel panel | |
| Edge banding | 3mm thick PVC edging on all worktop exposed edges | |
| Hardware fasteners | Zinc-plated steel cam-lock connectors with metal threaded inserts | |
| Foot glides | Nylon-tipped adjustable steel glides on cabinet and legs | |
| Cable grommet insert | ABS plastic cable management port with brush seal | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| L-shaped dual work surface | Provides split zones for computer work and document/supplement placement | |
|---|---|---|
| Embedded cable access port | Routes monitor, power and peripheral cables through worktop to below-desk management | |
| Perforated modesty panel | Conceals under-desk wiring and provides seated leg privacy, with slotted cable pass-throughs | |
| Integrated left storage cabinet | Includes closed storage compartment and open lower shelf for office supplies and files | |
| Adjustable leveling glides | Compensates for uneven floors to keep worktop stable and level | |
| Knockdown assembly design | Ships flat-packed for transport, assembles with included hardware without specialized tools | |
| Rounded worktop edge profile | Eliminates sharp corners to reduce user contact injury risk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Provides ample workspace and integrated storage for manager or director use | |
|---|---|---|
| Home office workspace | Fits residential office layouts for remote professional work and document storage | |
| Small open-plan workstations | Can be deployed in open office zones for individual focused work | |
| Dual-monitor computer work | 850mm main depth accommodates dual monitors, keyboard and peripherals with clear knee space | |
| Meeting prep work area | Side return surface provides extra space for documents, meeting materials and office devices |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance checks | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and stability requirements, applicable to clearance checks | |
| EN 13722:2004 | Furniture test methods for strength and durability of storage units, applicable to cabinet testing |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet panel performance | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and tables, applicable to structural stability and load | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, applicable to board emissions |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet panel performance; 2. GB/T 3327-2017: Performance standards for office desks and tables, applicable to structural stability and load; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, applicable to board emissions; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
