Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 2400 x 1800 x 750 mm | |
|---|---|---|
| Main worktop depth | 800 mm | |
| Side return cabinet width | 1200 mm | |
| Side return cabinet depth | 600 mm | |
| Side return cabinet height | 600 mm | |
| Knee well clear width | 1100 mm | |
| Knee well minimum clear height | 600 mm | |
| Desktop thickness | 50 mm | |
| Modesty panel dimensions | 1100 x 350 mm | |
| Right support leg diagonal brace footprint | 700 mm along floor | |
| Desktop overhang beyond left cabinet | 200 mm | |
| Vent cutouts on side of storage cabinet | Each slot 80 x 8 mm, 5 evenly spaced slots | |
| Edge banding thickness | 2 mm | |
| Right support leg steel section | 60 x 40 mm rectangular steel tube, 2.0 mm wall thickness | |
| Cable grommet inner diameter | 60 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
| Product net weight | 165 kg | |
|---|---|---|
| Desktop uniform static load capacity | 150 kg | |
| Recommended user capacity | 1 person | |
| Desktop surface abrasion resistance reference | ≥2000 revolutions (Taber CS-10 wheel, 500g load) | |
| Edge impact resistance reference | ≥15 N·m | |
| Leveling adjustment range | 15 mm per foot | |
| Drawer slide static load rating (reference) | 35 kg per drawer, ≥50000 open/close cycles | |
| Cabinet hinge cycle rating (reference) | ≥80000 open/close cycles | |
| Finish adhesion rating (reference) | Grade 1 (cross-hatch test, no coating detachment) | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25mm thick E0-grade medium density fiberboard (MDF) | |
|---|---|---|
| Desktop surface finish | Smoked dark brown horizontal wood veneer with matte polyurethane clear coat | |
| Desktop edge banding | Matching wood veneer edge trim, fully sealed | |
| Frame and leg structure | 2.0mm thick cold-rolled steel with dark grey powder-coated finish | |
| Modesty panel | 1.5mm thick powder-coated steel in matching dark grey matte finish | |
| Storage cabinet carcass | 18mm thick particleboard/MDF with matching wood veneer finish | |
| Cabinet base plinth | Powder-coated steel frame with integrated adjustable leveling glides | |
| Cabinet side ventilation panels | Matching wood-veneer panel with precision cut horizontal vent slots | |
| Drawer slides (inferred) | Full-extension ball-bearing steel slides | |
| Surface coating VOC reference | Recommended ≤0.5 mg/m³ formaldehyde emission, ≤10 g/L VOC content | |
| Cabinet door hinges (inferred) | Cold-rolled steel concealed soft-close hinges, nickel-plated finish | |
| Cable management components (inferred) | ABS plastic cable grommets with brush seals, 0.8mm thick powder-coated steel under-desk cable tray |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left-side full-depth pedestal with internal compartments for filing and office supply storage | |
|---|---|---|
| Ventilation for active equipment | Side panel vent slots allow passive airflow for CPUs, printers or network equipment stored inside the cabinet | |
| Integrated cable management (inferred) | Desktop access grommets and under-desk cable routing channels below work surface | |
| Fixed work height | 750 mm finished work surface height, optimized for standard 450 mm seat height office task chairs | |
| Modesty panel privacy barrier | Full-width steel panel blocks view of seated user's legs from front of desk | |
| Stability bracing | Angled K-shaped steel leg assembly with floor contact points provides anti-wobble rigidity for full desk span | |
| Leveling adjustment | Adjustable glides at all floor contact points allow compensation for uneven floor surfaces | |
| Extended desktop work surface | Overhanging desktop section above left cabinet provides additional work space adjacent to primary seated position | |
| Soft-close storage operation (inferred) | Drawer slides and cabinet hinges include soft-close damping to prevent slamming and reduce noise in private office environments | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 5packages total | |
|---|---|---|
| Largest shipping carton dimensions | 2450 x 850 x 120 mm (for main worktop panel) | |
| Total shipping gross weight | 190 kg | |
| Total shipping volume (CBM) | 0.62CBM | |
| on-site assembly time | 90 minutes for 2 trained assembly technicians | |
| 40ft HQ container loading quantity (knock-down) | 125units | |
| 40ft HQ container loading quantity (knock-down flat-pack) | 125units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Executive private office | Suitable for senior management and C-suite office spaces, providing generous work surface and integrated storage for a professional, organized workspace | |
|---|---|---|
| Managerial work area | Appropriate for department manager offices 25sqm in size, with space for visitor seating in front of the desk | |
| Corporate boardroom ancillary workspace | Usable as a supplemental work surface or presentation preparation desk adjacent to board meeting rooms | |
| Commercial office furniture procurement specification | Suitable for commercial office projects, government facilities and corporate headquarters fit-outs | |
| Hybrid work dedicated home office | Applicable for high-end residential home office use for remote executives | |
| Recommended matching furniture | Pair with mid-back/ high-back executive task chair with 450 mm seat height, matching wood-veneer visitor seating and lateral file cabinet for supplemental storage | |
| Department manager work area | Appropriate for mid-level department manager offices 25sqm in size, with 1200 mm clear space in front of the desk for 2 visitor seats | |
| Commercial office fit-out projects | Suitable for bulk procurement for corporate headquarters, government office facilities and co-working premium private office suites |
European market access and chemical requirements
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, applicable for verification of work surface height, clearance dimensions and functional sizing | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Safety, strength and durability requirements, applicable for structural load, stability and safety performance acceptance | |
| EN 13986:2004+A1:2015 | Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking, applicable for substrate panel performance verification |
US and Canada office-furniture standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desktop and cabinet structural performance, dimensional tolerance, and finish durability acceptance | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable for work height, knee well clearance, static load, stability and safety performance acceptance | |
| GB 18580-2017 | Limit of formaldehyde emission from wood-based panels and finishing products, applicable for substrate material emission acceptance for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desktop and cabinet structural performance, dimensional tolerance, and finish durability acceptance; 2. GB/T 3327-2016: Technical requirements for office desks, applicable for work height, knee well clearance, static load, stability and safety performance acceptance; 3. GB 18580-2017: Limit of formaldehyde emission from wood-based panels and finishing products, applicable for substrate material emission acceptance for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
