Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1800 x 1600 x 767 mm | |
|---|---|---|
| Main worktop thickness | 38 mm | |
| Storage return panel thickness | 18 mm | |
| Metal leg wall thickness | 1.2 mm | |
| Edge banding thickness | 2 mm | |
| Seated knee clearance height | 700 mm | |
| Knee clearance width (central seating bay) | 1200 mm | |
| Knee clearance depth under worktop | 600 mm | |
| Right storage cabinet external dimensions | 1200 x 600 x 680 mm | |
| Modesty panel dimensions | 1200 x 400 x 18 mm | |
| Cable grommet inner diameter | 60 mm | |
| Storage cabinet adjustable shelf depth | 560 mm | |
| Leg floor contact spread (left splayed legs) | 700 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Worktop evenly distributed static load capacity | 80 kg | |
|---|---|---|
| Drawer slide rated dynamic load per drawer | 25 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet hinge cycle rating | 80000 open/close cycles | |
| Product net weight (assembled) | 82 kg | |
| Recommended user weight capacity (seating bay) | 136 kg | |
| Worktop surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface layer | Scratch-resistant melamine laminate with light oak woodgrain finish | |
|---|---|---|
| Worktop core material | E0-grade particleboard core with low formaldehyde emission | |
| Left support legs | Powder-coated white tapered splayed steel legs | |
| Front modesty panel | Matte white MDF panel suspended under front worktop edge | |
| Storage cabinet exterior panels | Light oak melamine-faced particleboard with matching woodgrain | |
| Storage cabinet interior panels | White melamine-faced MDF with smooth wipe-clean surface | |
| Edge banding material | 2mm thick PVC edge banding with color-matched finish | |
| Cabinet hardware | Soft-close steel drawer slides and zinc-alloy concealed hinges | |
| Leveling feet | Nylon-base adjustable height glides on storage cabinet base | |
| Cable management components | PVC cable grommets and steel under-desk cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed-height work surface | Worktop set at 767mm height optimized for ergonomic seated office task work | |
|---|---|---|
| Integrated right-side storage return | Attached cabinet provides enclosed storage for documents and office supplies | |
| Soft-close drawer operation | Damping slides close drawers silently without slamming, full 3/4 extension for access | |
| Adjustable cabinet shelving | One removable interior shelf in return cabinet supports variable storage heights | |
| Front cable management | Suspended modesty panel conceals under-desk cable runs and desktop wiring routes | |
| Floor leveling adjustment | Integrated glides on storage cabinet adjust up to 10mm to correct uneven flooring | |
| Central open knee bay | Unobstructed central opening allows full chair swivel and leg movement for seated users | |
| Stable splayed leg support | Angled left steel legs distribute weight to resist tipping during normal office use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Fits single manager or director workspaces with professional light wood aesthetic, provides ample work and storage space | |
|---|---|---|
| Dedicated home office | Scandinavian minimalist design complements residential interiors while supporting full workday computer and document tasks | |
| Small team workstation | Works for senior team members in open plan offices requiring integrated storage without separate credenza furniture | |
| Hybrid work setup | Supports laptop, monitor and office accessories with cable management to maintain a tidy work surface | |
| Professional meeting adjacent work area | Fits in small meeting rooms for on-site document review and laptop-based collaboration work |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic and office tables, applicable for structural performance verification | |
|---|---|---|
| EN 1730:2012 | Test methods for tables, applicable for stability, strength and fatigue load assessment | |
| EN 12727:2000 | Performance requirements for office storage furniture, applicable for return cabinet hardware testing |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel desk structural integrity verification | |
|---|---|---|
| GB/T 3327-2016 | Performance standards for office desks and tables, applicable for static load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E0 grade core material acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable for melamine worktop durability validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel desk structural integrity verification; 2. GB/T 3327-2016: Performance standards for office desks and tables, applicable for static load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0 grade core material acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable for melamine worktop durability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
